Characteristics:
·Imported Schott optics fromGermanyreduces optical distortion, increases clarity and depth of focus.
·All the Optical lenses are moistureproof,mildewproof and anti-reflected treated.
·Excellent optical performance and long span usage.
·Five-step drum magnification for eyepiece. Sclera vein could be observed under the 40x magnification
·All the joints can be connected by accessories with international standards.
Specifications：
|
Microscope Type |
Galilean stereoscopic microscope |
|
Objective Magnification |
Five Steps Drum Magnifications |
|
Eyepiece |
12.5x |
|
Magnifications（Field of View) |
6x（φ33mm）、10x（φ22.5mm）、16x（φ14mm）、25x（φ8.8mm）、40x（φ5.5mm） |
|
Pupil Distance |
55mm～75mm |
|
Diopter Adjustment |
－5D～+3D |
|
Slit Width |
0mm～9mm adjustable（Slit is round when the silt width is9mm） |
|
Slit Height |
1mm～8mm adjustable |
|
Slit Angle |
0°-180°adjustable |
|
Slit Inclination |
5°、10°、15°、20°,four steps adjustable |
|
Diameter of Light Spot |
φ9mm、φ8mm、φ5mm、φ3mm、φ2mm、φ1mm、φ0.2mm |
|
Filter |
Heat Absorption、Grey、Redfree、Cobalt Blue |
|
Illumination Bulb |
12V/30W Halogen Bulb |
|
Input Voltage |
AC220V±22 V ,AC110V±11 V |
|
Electrical Safety Standard |
Conform to Standard:IEC601-1,Class I, Type B |
|
Packing Volume |
720mm*495mm*480mm |
|
Total Weight |
24kg |
|
Optional Accessories |
R Type,T Type Applanation Tonometer、Measuring Eye Piece、Trihedron Lens、Gonioscope、Funduscope、Aspheric Lens、Teaching Tube |
