MIC-20J slit lamp microscope is an newly developed ophthalmologic optical instrument used to check preocular and intraocular. Based on the principle of optical magnification, it is designed for accurate check on pathological changes, such as cornea, eyelid, front chambers, sclera, iris, crystalline lens vitreous body and retina etc. by means of tidy light section projected from slit lamp. Fitted with other accessories, it can be used to check eye ground, tonometry, and to measure width of cornea. It can also be used for demonstration, photography and camera shooting.
Unique characteristics:
1. International downside illumination design
2. This new slit lamp microscope has high resolution image with long depth field of view, it is the first model made in China without any shadow lights in the field of view.
3. Special optical design making illumination to maximum 160,000 LUX without any attenuation
4. 8 inch, 10inch tablet PC is optional according to customer’s requirement (photography, video recoding, communication)
5. Fully digital control of lifting and illumination, not manual
6. Press switch button can make slit illumination to maximum without any adjustment.
7. All switch and button is with LED light due to dark room operation.
9. 85V~250V AC wide voltage, digital switch
button with short circuit, overload protection which makes the slit lamp
microscope for wider arrange application.8. The table is made of water proof and anti-scratch
polymer materials
Features:
※Binocular head: 12° included angle,
※Magnification of binocular head:12.5X
※Total magnification: 25X,16X, 10X
※Zooming system: 1.6X,1X, 0.6X
※Resolution LP/mm: 180,160, 120
※Sliding plate, Chin rest, Hand rest
Technical Data
|
MIC-20J slit lamp microscope specification |
|||
|
Rotation angle |
Horizontal 180° |
||
|
Light spot diameter（mm） |
7 steps: 0.5，1，2，3，5，10，14 |
||
|
Slit width |
0 -14 mm continuously adjustable |
||
|
Magnification of binocular head |
12.5X |
||
|
Included angle of binocular head |
12° |
||
|
Zooming system |
1.6X |
1X |
0.6X |
|
Total magnification |
25X |
16X |
10X |
|
Linear field of view mm |
9.0 |
14.2 |
23.1 |
|
Exit pupil diameter mm |
1.5 |
2.3 |
2.3 |
|
Exit pupil distance mm |
20.6 |
||
|
Resolution LP/mm |
180 |
160 |
120 |
|
Working distance |
108 mm |
||
|
Linear field of view mm |
9.0-23.1 mm |
||
|
Interpupillary distance |
54-75 mm |
||
|
Diopter range |
±5 diopter |
||
|
Sliding plate |
Left and right movement:110 mm Forward and backwardmovement:100mm Vertical lifting:30mm Fine adjustment in horizontal10mm |
||
|
Chin rest |
Lifting range70mm |
||
|
Hand rest |
At any angle |
||
