Five step drum magnification for eyepiece. Sclera vein could be observed under the 40X magnification.
All the optical lens is moisture proof, mildew proof and anti-reflected treated.
Large spot diameter, slit length reach to14mm, more comprehensive view of the eye condition.
Multi-coated optical technology, image is clear and bright, the view field is wide.
Osram light bulbs, small heat, high-brightness, spot uniformity.
Handrail design, user friendly and convenience of patients
Oversized joystick space, mobile base does not touch the hand.
All the joints can be connected by accessories with international standards.
|
Microscope |
Microscope type |
Galilean stereoscopic microscope |
|
Magnification selection |
5 steps by drum rotation |
|
|
Eyepiece |
12.5x |
|
|
Magnification and field of view |
6×（φ33mm）、10×（φ22.5）、16×（φ14mm）、 25×（φ8.8mm）、40×（φ5.5mm） |
|
|
Interpupillary adjustment |
50mm ~82mm |
|
|
Diopter adjustment |
+5D ~ -5D |
|
|
Base |
Side shift |
110mm |
|
Depth shift |
90mm |
|
|
Up-down shift |
30mm |
|
|
Chin rest |
Up-down |
80mm |
|
Fixation target |
Red LED |
|
|
Illumination system |
Slit height |
0 ~14mmcontinuous ( when14mm, slit becomes a circle) |
|
Slit angle |
0︒ ~ 180︒ adjustable |
|
|
Slit inclination |
0︒、5︒、15︒、20︒ |
|
|
Diameter of light spot |
Ф14mm、Ф10mm、 Ф5mm、 Ф3mm、Ф2mm、Ф1mm、Ф0.2mm、Ф1mm和Ф1-14mmcontinuous |
|
|
Filter |
Heat absorption, Grey, Red free, Cobalt blue |
|
|
Bulb |
12V 50W halogen lamp |
|
|
Power |
Input voltage |
110V/220V AC |
|
Frequency |
50H/60Hz |
|
|
Power consumption |
68VA |
|
|
Weight and size |
Gross weight |
18kg |
|
Net weight |
16kg |
|
|
Package dimension |
690mm（L）×440mm（W）×420mm（H） |
