Characteristics:
Split line provides the function of accurate focusing and makes the focusing more accurate and convenient;
The use of pupil alignment spots eliminates stray light effectively;
Targeting and focusing of infrared light improves greatly the feeling of patient comfort;
Flash strength of eight adjustable forwards ensures suitable exposure;
Functions of using periphery internal fixation standard, object images stitching and field-of-view can be expanded to 77º
Design of no eyepiece and colorful screen can target and focus conveniently and directly.
With the function of right/left eye auto detection.
Two types for option, one of them is the high-grade type, which has the functions of automatically tracing, automatically focusing and automatically filming.
Specifications:
|
Images |
Fundus color/red-free photography |
|
View field |
45º |
|
Working Distance |
41mm |
|
Dioptric Compensation for Patient’s Eyes |
-34D~+35D total -15D～+13D with no dioptric lens -34D～-14D with minus dioptric lens +12D～+35D with plus dioptric lens |
|
Min Pupil Diameter |
Φ3.7mm |
|
Internal Fixation Target |
3 in center,6 inthe periphery with 60 º detent interval |
|
Backward and Forward Movement |
45mm |
|
Left and Right Movement |
80mm |
|
Up and Down Movement |
30mm |
|
Chinrest Movement |
65mm |
|
Input Voltage |
AC220±22V/50Hz±1Hz、 AC110V±11V/60Hz±1Hz |
|
Input Power |
300VA |
|
Fuse |
AC250V T3A |
|
Light |
12V/30W, Halogen |
|
Electrical Safety Standard |
GB9706.1-1995、ClassI Type B |
|
Voltage Transformer Thermal Circuit Breaker |
130℃ |
