MIC-LL5X1 Slit Lamp Microscope
The product with complete function and reliable performance could meet the ophthalmic requirements.
Characteristics：
• Galilean stereoscopic microscope provides the practitioners unsurpassed clarity and sharpness, and avoid double images.
• Five-step drum magnification.
• Optional accessories: Teaching Tube, CCD Camera and Tonometer.
Specifications:
|
Microscope Type |
Galilean stereoscope |
|
Objective Magnification |
Five steps drum magnifications |
|
Eye Piece |
12.5X |
|
Magnifications (Filed of View) |
6 x (33mm) 10x(22.5mm) 16x (14mm) 25 (8.8mm) 40(5.5mm) |
|
Pupil Distance |
55 mm~75 mm |
|
Diopter Adjustment |
-5D~+3D |
|
Slit Width |
0mm～14mm adjustable(slit is round when the slit width is 14mm) |
|
Slit Height |
1mm～14mm adjustable |
|
Slit Angle |
0～180 adjustable |
|
Diameter of Light Spot |
14mm、9mm、5.5mm、0.3mm |
|
Slit Inclination |
No |
|
Filter |
Heat Absorption, Redfree, Cobalt Blue |
|
Illumination Bulb |
6V20W Halogen Bulb |
|
Input Voltage |
AC220V22 V；AC110V11 V |
|
Electrical Safety Standard |
Conform to Standard IEC601-1,Class I, Type B |
|
Total Weight |
23Kg |
|
Packing Volume |
720mm495mm480mm |
|
Optional Accessories |
Applanation Tonometer、Trihedron Lens、Gonioscope、Funduscope、Aspheric Lens,Teaching Tube |
