Specifications:

Display model

Separated

Optical quality

Standard

Field of view

Maximum 53°

NO pupil scatter photographing

support

Minimum pupil diameter

3.3mm

Color digital collector

12M pixel

Observation illumination

Infrared light

Refraction compensation range

±15D

Outside fixed viewing target



Five points fixed viewing target



Auxiliary para-position

Double point auxiliary focusing

Focusing method

Manual

Exposure method

Manual

Medical internet

Dicom 3.0 interface

Second display screen

Eye position recognition

Automatic

Optical incline angle

Horizontal ±30°

Vertical ±12.5°

Working distance

42mm±2mm

Operation stage

Standard

Nine points fixed viewing target

Optional


Minimum pupil photograph diameter3.3mm

More patients can be checked

Applicable for ophthalmology section use,

physical examination, diabetes patients fundus check.



Inner fixed digital collector

Inner fixed digital collector

Offer12Mpixel high definition color fundus image




Field of view single picture can reach maximum 53°

Assure precise fundus checking, avoiding missed diagnosis ratio, elevating checking ratio

Easy operation  Automatic para-position, focusing, exposure, 30 seconds for clear image

Optical incline with inner, exterior fixed viewing target, can photographing 180°fundus

Optical incline angle   Horizontal ±30°   Vertical ±12.5°

Newly designed five points, nine points inner fixed viewing target, guiding the eye movement, shooting from all angle

High successful photographing ratio

Easy to operate with high successful photographing ratio

Hard to operate, image differs too much, need training

Powerful patients management system, satisfy medical internetting

Standard Dicom 3.0 interface

Customize patients medical record for doctors, international standard.

MIC TECH products comparison with world top products   Color fundus
