Microscope type

Galilean parallel stereo microscope

Eyepiece

12.5x

Magnification and field of view

6×（φ35mm）、10×(φ23mm), 16×（φ14mm）、25×（φ9mm）,40×（φ5.5mm）

Interpupillary adjustment

55mm ~ 75mm

Diopter adjustment

+5D ~ -5D

Fixed lamp

Red lamp

Slit width

0 ~ 14mm adjustable

Slit angle

0°-180°adjustable

Slit length

0 ~ 14mm adjustable

Slit inclination

5°, 10°,15°, 20°

Aperture diameter

Ф9mm 、Ф8mm、 Ф5mm 、 Ф3mm 、Ф2mm 、Ф0.2mm or Ф14mm 、Ф10mm、 Ф8mm 、 Ф5mm、 Ф3mm、Ф2mm 、Ф0.2mm

Filter

Heat absorption, Grey, Red free, Cobalt blue

Bulb

12V 30W or 12V 50W halogen lamp

Input voltage

110V/220V AC

Frequency

50H/60Hz

Power consumption

80VA

Electro elevating table, beam splitter&adapter camera

Gross weight

25kg

Net weight

22kg

Package dimension

770mm（L）×620mm（W）× 380mm（H）
