Microscope |
Microscope type |
Converging stereoscopic microscope |
|
Magnification selection |
Two steps magnification |
|
|
Eyepiece |
10x |
|
|
Magnification and field of view |
10×（φ18mm）、16×（φ14.5mm） |
|
|
Interpupillary adjustment |
50mm ~82mm |
|
|
Diopter adjustment |
+5D ~ -5D |
|
|
Base |
Side shift |
110mm |
|
Depth shift |
90mm |
|
|
Up-down shift |
30mm |
|
|
Chin rest |
Up-down |
80mm |
|
Fixation target |
Red LED |
|
|
Illumination system |
Slit width |
0 ~9mmcontinuous ( when9mm, slit is round shape) |
|
Slit angle |
0︒ ~ 180︒ adjustable |
|
|
Slit height |
1-8mmcontinuous |
|
|
Diameter of light spot |
Ф9mm、Ф8mm、 Ф5mm、 Ф3mm、Ф2mm、Ф1mm、Ф0.2mm |
|
|
Filter |
Heat absorption, Grey, Red free, Cobalt blue |
|
|
Bulb |
12V 50W halogen lamp |
|
|
Power |
Input voltage |
110V/220V AC |
|
Frequency |
50H/60Hz |
|
|
Power consumption |
68VA |
|
|
Weight and size |
Gross weight |
18kg |
|
Net weight |
16kg |
|
|
Package dimension |
690mm（L）×440mm（W）×420mm（H） |
