Feature:

Advanced third-generation technology

Hartman testing method

Green LED light source, direct reading, no need for ABBE compensation

Wide dioptor and prism measurement range for Spherical lens, Cylindrical lens, Progressive multi-focal lens, hard and soft contact lens

Low transmittance lens and low astigmatism lens measurable

Bigger TFT touch screen- Leader of simple and fast operation

PD, PH, UV, and Thermal printing function

Many technology and design patents

Main technical index

Spherical power:

－25 m^-1～＋25 m^-1

Cylindrical power:

－9.99 m^-1～＋9.99 m^-1

ADD power:

－9.99 m^-1～＋9.99 m^-1

Spherical power(contact lens):

－20 m^-1～＋20 m^-1

Axis:

0～180°, Prism basal angle: 0～360°, 1°increments;

Prism power:

0～15△(horizontal direction)

0～15△(vertical direction)

0.01△increments

Applicable lenses:

φ10mm～φ90mmdia ;  ≤20mmcenter thickness

Applicable frame leg length:

0～158mm

PD measurement:

PD=42mm～82mm

UV Transmittance：

qualitative measurement

Power source:

DC 12V，45VA

Power adapter:

Input AC 110V-240V，50Hz-60Hz

Output DC 12V, 45VA

Measurement:

235mm(length)*246mm(width)*487mm(height)

Weight:

6kg
