MIC-CD3E operation microscope has a super optics system; it can give the biggest depth of field. And it has a special diaphragm, so we can change the depth of field slightly. For ophthalmology.

Specification



New changing diaphragm give you perfect depth of field

Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens180mm

Binocular tube: 30°~90°variable angle binocular tube, add new pupil distance adjustment

Magnification: 6:1 zoom, motorized, magnification 4.5x~27.3x; field of view Φ44~Φ7.7mm

Coaxial assistant’s binocular tube: manual 3-step changer, total magnification 6.8x,11.4x,18.2x; field of view Φ34mm,Φ20mm,Φ13mm

Coaxial illumination: illumination diameter of light spot Φ50mm, illumination intensity 100000lux

Objectives: f175mm(200mm,250mmetc )

Focusing: motorized, range +/-25mm, speed 33s/whole distance

X-Y translator: move in X-Y direction motorized, range +/-30mm

Maximum length of arm:1200mm

Stand: swing angle of the carrier arm 0 ~300°,height from objective to floor800mm, Foot switch waterproof, 8 function steps

Weight:164kg
