MIC-ZL16 ophthalmic surgical microscope

Ophthalmic-specific:

1. High-definition continuous variable magnification optical system

2. Coaxial illumination of cold light source dual bulb conversion

3. Foot control electric focusing and foot control lighting switch

4. New balance rack mover with X-Y plane

5. Microcomputer centralized control system and the image system

6. Optional splitter, the Teach microscope and digital camera system and CCD camera system as well as the xenon lamp lighting

Technical parameters:

Microscope

Magnification of eyepiece: 10/22B

Working Distance: 200mm

The primary mirror Magnification: 4-24 electric step less zoom

Secondary mirror magnification: 6, 1,16

Field of view diameter: 58mm-11mm

IPD adjustment range: 55mm-75mm (continuously adjustable)

Diopter adjustment range: ± 6D (continuously adjustable)

The speed and range of fine focusing: ≤ 2mm / s, 40mm

X / Y moving speed and range: ≤ 2mm / s, 40mm * 40mm

Light Source

Lighting type: 6 ° +0 ° coaxial illumination

Lighting bulbs: 15V/150W halogen lamps (optional 250W xenon lamp)

Lighting control: continuous digital regulation

Maximum illumination of the object plane: ≥ 80000-120000Lx

Optional xenon lamp lighting, illumination of up to 180,000 Lx

Membrane touch switch and LCD display design, reliable

Maintain the usual parameters of the 12 doctors

Frame

Arm stretch radius: 1200mm

Vertical adjustment range: 450mm

Uses:

MIC-ZL16 type surgical microscope carefully designed by the famous optical experts machine adopts advanced modular, digital, personalized design concepts, products widely used in ophthalmic microsurgery.

Features:

1. The main microscope using a state-of-the-art parallel light electric continuous zoom technology, zoom factor of 0.45-2.4, high-definition, large depth of field, layering, can meet a variety of deep surgical observation; eyepiece operative field, the operation The distance is less than 40mm, operative prolonged eye, the body will not fatigue.

2. Instrument uses coaxial cold light source fiber optic lighting, excellent three-dimensional, with retinal protection devices and foot control lighting switch (to facilitate vitrectomy).

3. Vice microscope for three drum zoom, and the main microscope at a 90 ° postural, the same optical path.

4. Independent electrical control system, installation and maintenance convenient.

5. Tune pour institutions the surgery face special viewing angle can be set.

6. Microcomputer program control, step less dimming, speed control system.

7. With foot controlled XY plane mover, moving range XY:> 40mm. Can be reset to zero.

Optional Accessories:

Splitter, monocular Teach mirror, digital camera interface, 1/3 inch CCD camera interface, expert video image processing system, and the optional xenon lamp lighting.
