A surgical operation microscope is to used for the surgical operations, such as neurosurgery facial features section and orthopedics...etc. to fit together, repair in the organizations, such as capillaries and nerve...etc. of show minute details stereoscopic enlarge, precise and optical instrument that operate.

A surgical operation microscope is constitute by the optical system of an observation, including the thing mirror, variable enlarge the optical system, eyes mirror of the rate, and illuminate the system, support, electricity to equip to constitute, a surgical operation microscope is to combine a design structure, requesting according to the different usage of customer, installing various homologous accessories.

Main technique index sign:

1, optical system resolution: 100 Line to / mm (25 X hour nation standard 86 Line to international standard 90 Line to)

2, the thing mirror work distance of the surgical operation microscope: the200 mm250 mm300 mm400 mm(the400 mmchooses to go together with)

3, the big scope is dynamoelectric to become continuously doubly, become to compare doubly: 6.5: 1 greatest visual fields, big views are deep

4, the main mirror of the series GS-2020 surgical operation microscope enlarges the magnification:



Big thing mirror

Enlarge the magnification

See a diameter

200mm

5.3X~32X

38—8.5mm

250mm

4.0X~26X

48—10.5mm

300mm

3.6X~22X

66—12.6mm

5, eyes mirror: The 12.5 X/27.5 wide-angle eyes mirror, inside place the nicety to measure tiny row the Chinese foot separately; Space value: The0.1 mmengraves one degree long10 mm, make a convenience of in the surgical operation process, the nicety measures the size of the muscle body organization

6, the eyes be apart from:55 mm-75mminside place the synchronous machine

7, the big thing mirror is apart from the ground:850mm~1400mm

8, thick adjust the scope:550mmTiny adjust the scope:40mm

9, the horizontal arm launches the length:1200mmhorizontal arm returns the angle: Equilibrium support in the type space of 360 degrees damping is easily stable, free angle of ten thousand operate toward suitable for any surgical operation of angle of arm

10, mark to go together with: The CCD shoots the elephant head and optical systems

11, an eyes assistant's mirror: Enlarge the magnification and main mirrors synchronously, the level revolves 180°the perpendicularity revolve 360°

12, choose to go together with: The figures camera and optics connect

14, inside place to illuminate with the stalk cold light source, the bright degree of 15 V/150 W has no class to regulate, placing the 250 W xenon light cold light source outside

15, the microscope is in front and back the or so angle of elevation ± 45° of the angle of elevation 360°

16, enlarge the magnification manifestation micro-computer control, the LED figures manifestation,
