Compact structure and complete functions.
Characteristics:
•Compact structure and complete functions.
•4×～24×zoom magnifications, horizontal movement of foot control and fine focusing.
•Germanyimported Schott optics ensure the sharp image and even field of view.
•Applied in operations and fine examinations of ophthalmology, ENT ,surgery, etc.
Specifications:
|
Eyepiece Magnification |
12.5×/16B |
|
Diopter Adjustment |
±6D |
|
Pupil Distance |
50mm～75mm |
|
Visual Angle of Eyepiece |
30°～90°(Eyepiece moving between 0°～180°is optional ) |
|
Magnifications for Main Microscope (Diameter of Field) |
4×～24×（41.5mm～7.5mm） |
|
Objective Lens |
f=200（f=175/250/300 is optional） |
|
Maximal Resolution |
119LP/mm |
|
Working Distance |
190mm |
|
Illumination Source |
15V/150W，Medical Cold-reflection Halogen Bulb |
|
Illumination Type |
6°+0° Coaxial Illumination |
|
Coaxial Illumination |
≥40,000lx |
|
Filters |
Orange filter（cobalt filter is optional） |
|
Reaching Radius of Arm |
1020mm |
|
AdjustableVerticalRange |
250mm |
|
Fine Focusing Range and Speed |
30mm，≤2mm/s |
|
Speed for X-Y and Range |
50mm×50mm，≤2mm/s |
|
Input Voltage |
AC220V±22v/ 50Hz±1Hz、AC110V±11v / 60Hz±1Hz |
|
Power |
200VA |
|
Fuse |
T2AL 250V (51S-040H)、T4AL 125V (51S-080L) |
|
Electrical Safety Standard |
Executive Standard:GB9706.1-2007、Class I |
|
Packing Volume |
0.418m, 2cartons |
|
Total Weight |
87kg |
