Be applicable to the microsurgery surgical operations, such as facial features section, dentistry, orthopedics, microsurgery, ophthalmology and gynecology...etc. The Its  domestic found  of inside  become the  burnt big  thing mirror design, make that model number machine suited a cavity body surgical operation specially.

Main technique index sign:

1. The work distance: The 160 mms mms-270ses is dynamoelectric to become continuously burnt.

2. Enlarge the magnification: The 28X -3X hand moves to become continuously doubly.

3. The visual field diameter: Ф9 mms-Ф75 mms of

4. The view is deeply the scope:4mm-50mm

5. Eyes mirror: 12.5X/Ф27.5mm

Basic function

Choose the typical model number

Become the burnt big thing mirror focal distance 250~150mm

250mm

200mm

150mm

Enlarge the multiple

2.6X~17X

3X~20X

3.8X~25X

The view is deep

65~6mm

35~4.5mm

25~3mm

See a diameter

Ф100~17mm

Ф80~15.5mm

Ф60~12.5mm

6. The eyes be apart from to regulate the scope:55mm-75mm

7. The See the degree regulates the scope: 5D±

8. Equilibrium type machine of the spring coil arm

9. Biggest stretch out the distance:1100mm

10. The microscope work is highly:850 mm-1320 mm( the big thing mirror goes to the ground)

11. Thick adjust the scope:470mm

12. The light beam is dynamoelectric to adjust the burnt scope:110mm

13.The Move ten thousand regulate toward arm, the is in front and back the or so angle of elevation ± 90° of the angle of elevation 180° of the microscope

14.The Cold light source: the 250w xenon light, the together an adjustable lighting of stalk, a surgical operation request.

15. The Light mirror of: White/ the green convert

16. Power supply: The total of AC220V/50Hz consumes the 550W of ≤Characteristics: An eyes of single are deeply the surgical operation microscope of cavity.

Dalian becomes continuously to compare doubly 6:1.

High and clear become the stereoscopic optical system of elephant, system resolution:100 line/ mm of hour of 25X

Dynamoelectric regulate inside become the burnt big thing mirror, become the burnt scope110 mm

The much more deluxe layer lies the quality film  cent light mirror, installing the colorful optics of CCD to connect a people's system.

Germany imports the spring coil arm machine of annoy the spring coil module,
