It have a X-Y translation machine on the cantilever, so the head of the operation microscope can move left, right, forward and back. The optics system is a copy of MIC-CD4A
MIC-CD4B operation microscope can be used in orthopedics, plastic, hand surgery and ophthalmology surgery.
Specification
|
Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens125mm. |
|
Binocular tube: high brightness 45°binocular tube |
|
Magnification: manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm |
|
Coaxial assistant’s binocular tube: manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm |
|
Coaxial illumination: illumination diameter of light spot Φ50mm, illumination intensity 60000lux |
|
Objectives: f200mm(175mm,250mmetc ) |
|
Focusing: motorized, range +/-25mm, speed 33s/whole distance X-Y translator, move in X-Y direction motorized, range +/-30mm |
|
Maximum length of arm:1130mm |
|
New stand: swing angle of the carrier arm 0 ~300°,height from objective to floor800mm<H<1250mm, Foot switch, waterproof, 6 function steps |
|
Weight:115kg |
