Feature
Large diameter, wide eyes microscope optical fiber, Stereo sense is strong, high resolution, image is clear.
Primary mirror has 6 movements of degrees of freedom, easily for manual adjust
Secondary and primary mirror 90 degrees, with light Postures, manual consecutively variable times.
Aesthetically pleasing, electric foot control operation is more reliable and fine-tuning and convenient.
Specification
|
|
Item/Type |
MIC-ZJ8A |
|
Microscope |
Eyepiece |
45 ºbinocular lenses for one people |
|
10x Eyepiece, wide-angle, can adjusting ocular angle and have protect device, oxyopter adjustment：binocular±5 |
||
|
Tilting range in pitching |
-45º ~ 45º |
|
|
Tilting range in swing |
-30º ~ 30º |
|
|
Pupil Distance |
55~75mm |
|
|
Magnification |
5X~20X |
|
|
Diameter of viewing field |
38mm ~10mm |
|
|
Working distance |
≥160mm |
|
|
Fine focusing |
40±10mm |
|
|
Lighting system |
Lighting form |
Wide diameter optical fibers |
|
Illumination |
15V/150W halogen lamps |
|
|
Control model |
Four adjustment |
|
|
Intensity |
≥50000Lux |
|
|
Power control |
~220V,50Hz |
|
|
Frame part |
Stretch arm length |
1050mm |
|
Up-down adjustment range |
≥230mm |
|
|
Base size |
580 x560mm |
|
|
Foot control switch |
Electronic zoom |
*Video device（CCD, turn interface, target with and connecting cables, assistant mirror camera, xenon lamp are as options.
