The main binocular and the assistant binocular are fixed in 180°and the coaxial illumination system can give the same visual field, the same magnification and the same illumination to the main binocular and the assistant binocular.
Specification
|
Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens160mm |
|
Binocular tube: 30°~90°variable angle binocular tube |
|
Magnification: 6:1 zoom, motorized, magnification 4.5x~27.3x; field of view Φ44~Φ7.7mm |
|
Coaxial assistant’s binocular tube, manual 3-step changer, total magnification 6.8x,11.4x,18.2x; field of view Φ34mm,Φ20mm,Φ13mm |
|
Coaxial illumination: illumination diameter of light spot Φ50mm, illumination intensity 100000lux |
|
Objectives: f200mm(300mm,350mmetc.) |
|
Focusing: motorized, range +/-25mm, speed 33s/whole distance |
|
X-Y translator: move in X-Y direction motorized, range +/-30mm |
|
Maximum length of arm:1200mm |
|
New stand: swing angle of the carrier arm 0 ~300°,height from objective to floor800mm, Foot switch, waterproof, 8 function steps |
|
Weight:164kg |
