Compared with MIC-CD3C, MIC-CD3D has a new luxury stand. It has two illumination systems in it, so the visual fields are very bright. Especially, the optics system can zoom motorized by the foot switch. For ophthalmology.
Specification
|
Eyepieces: magnification: 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens160mm |
|
Binocular tube: 30°~90°variable angle binocular tube, add new pupil distance adjustment |
|
Magnification: 6:1 zoom, motorized, magnification 4.5x~27.3x; field of view Φ44~Φ7.7mm |
|
Coaxial assistant’s binocular tube: manual 3-step changer, total magnification 6.8x,11.4x,18.2x; field of view Φ34mm,Φ20mm,Φ13mm |
|
Coaxial illumination: illumination diameter of light spot Φ50mm, illumination intensity 100000lux |
|
Objectives: f175mm(200mm,250mmetc ) |
|
Focusing: motorized, range +/-25mm, speed 33s/whole distance X-Y translator: move in X-Y direction motorized, range +/-30mm |
|
Maximum length of arm:1200mm |
|
New stand: swing angle of the carrier arm 0 ~300°,height from objective to floor800mm, Foot switch, waterproof, 8 function steps |
|
Weight:164kg |
