The product is the coaxial illumination operation microscope for one man. It is applied in various surgery operations.

Characteristics:

·ZOOM magnification system, 4X21X continuous adjustment.

·Germanyoptical lens which provides sharp image and even filed.

·Cold light source fiber illumination does no harm to tissues.

·Convenient operation benefits from unique lifting turn-off.

·Applicable in Stomatology, Gynecology, Hand surgery and ENT.

Specifications:

Eyepiece Magnification

12.5×/16B

Objective Lens

f=250

Working Distance

240mm

Magnification for Main Microscope

21×zoom magnification

Diameter of Field

9.5mm50mm

Diopter Adjustment

±7D

Pupil Distance

50mm80mm

Maximal Resolution

112 LP/mm

Illumination Source

15V/150W, cold reflection medical halogen bulb

Illumination Type

6°coaxial illumination

Coaxial Illumination

≥35000lx

Reaching Radius of Arm

1210mm

AdjustingVerticalRange

760mm1360mm

Fine Focusing Range

10mm

Input Voltage

AC220V±22V/50Hz±1HzAC110V±11V/60Hz±1Hz

Power

170VA

Fuse

AC250V T2.0AAC125V T4.0A

Electrical Safety Standard

Executive Standard GB9706.1-2007 Class

Packing Volume

0.24m31 carton

Total Weight

48kg
