The product is a simple coaxial illumination operation microscope for one man. It is portable, compact
Characteristics:
•Binocular operation microscope designed for single man can meet the requirements of general ophthalmic surgery.
•Germanyoptical lenses are all multi-coated. Image is clear and view field is even.
•6°+0 coaxial illumination provides the red reflex.
•Reaching radius of microscope arm increases to1030mm, which provides surgeon larger operation range.
•Cortical remnants on the posterior capsular can be clearly observed by the 6°+0° coaxial illumination.
•Position screw can protect the arm at any location from moving.
Specifications:
|
Eyepiece Magnification |
12.5× |
|
Objective Focus |
f=200 |
|
Working Distance |
190mm |
|
Magnification for Main Microscope |
5.3×、8×、12× steps |
|
Diameter of Field |
F37mm、F25mm、F16.7mm |
|
Diopter Adjustment |
±7D |
|
Pupil Distance |
50mm～80mm |
|
Maximal Resolution |
100 LP/mm |
|
Illumination Source |
12V/100W,cold reflection medical halogen bulb |
|
Illumination Type |
6°+0°cold light coaxial illumination |
|
Coaxial Illumination |
≥30000lx |
|
Reaching Radius of Arm |
1030mm |
|
AdjustableVerticalRange |
±200mm |
|
Fine Focusing Range |
30mm |
|
Input Voltage |
AC220V±22V/50Hz±1Hz、 AC110V±11V/60Hz±1Hz |
|
Power |
120VA |
|
Fuse |
AC250V T1.25A、AC125V T2.5A |
|
Electrical Safety Standard |
Executive Standard GB9706.1-2007 Class Ⅰ |
|
Packing Volume |
0.24m3，1 carton |
|
Total Weight |
51kg |
