Feature
Large diameter, wide eyes microscope optical fiber, Stereo sense is strong, high resolution, image is clear.
Secondary and primary mirror 90 degrees, with light Postures, manual consecutively variable times.
Aesthetical pleasing，electric foot control operation is more reliable and fine-tuning and convenient.
Specification
|
|
Item/Type |
MIC-ZJ5B |
|
|
Primary mirror |
Secondary mirror |
||
|
Microscope |
Eyepiece |
10.0 wide-angle |
12.5 wide-angle |
|
Pupil Distance |
55~75mm |
||
|
Diopter |
±5 º(binocular) |
||
|
Magnification |
5X~20X |
||
|
Field of view |
10.5~50mm |
||
|
Working distance |
≥160mm |
||
|
Fine focusing |
40±10mm |
||
|
Lighting system |
Lighting form |
Wide diameter optical fibers |
|
|
Illumination |
15V/150W halogen lamps |
||
|
Control model |
Four adjustment |
||
|
Intensity |
≥50000Lux |
||
|
Power control |
~220V，50Hz |
||
|
Frame part |
Stretch arm length |
1050mm |
|
|
Up-down adjustment range |
≥230mm |
||
|
Base size |
580 x560mm |
||
|
Foot control switch |
Electronic zoom |
||
