MIC-CD3B is designed for ophthalmology too. It have a X-Y translation machine on the end of the second arm, so the head of the operation microscope can move left, right, forward and back. The optics system is a copy of MIC-CD3A.

Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens125mm

Binocular tube: high brightness 45°binocular tube

Magnification: manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm, Coaxial assistant’s binocular tube

Coaxial assistant’s binocular tube

manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm

Coaxial illumination: illumination diameter of light spot Φ50mm, illumination intensity 60000lux

Objectives: f200mm(175mm,250mmetc )

Focusing: motorized, range +/-25mm, speed 33s/whole distance

Maximum length of arm:1100mm

Stand: bran-new economical stand, Foot switch, waterproof

Weight:115kg
