The MIC-CD6B is the bran-new multifunctional operation microscope of MIC TECH. It has perfect optics system and the biggest depth of field. It can be used in ophthalmology surgery, Neurosurgery, dentistry, Orthopedics, E.N.T Dept.
Specification
|
New changing diaphragm give you perfect depth of field |
|
Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens180mm. |
|
Binocular tube: 30°~90°variable angle binocular tube, add new pupil distance adjustment |
|
Magnification: 6:1 zoom, motorized, magnification 4.5x~27.3x; field of view Φ45~Φ7.5mm |
|
Coaxial assistant’s binocular tube: manual 3-step changer, total magnification 6.4x,10.8x,17.3x; field of view Φ31mm,Φ19mm,Φ12mm |
|
Coaxial illumination: illumination diameter of light spot Φ50mm, illumination intensity 100000lux |
|
Objectives: f200mm(175mm,250mmetc.) |
|
Focusing: motorized, range +/-25mm, speed 33s/whole distance |
|
X-Y translator: move in X-Y direction motorized, range +/-30mm |
|
Maximum length of arm:1200mm |
|
Stand: swing angle of the carrier arm 0 ~300°,height from objective to floor800mm, Foot switch, waterproof, 8 function steps |
|
Weight:164kg |
