Electromagnetic lock and balance technology of the microscope ensure the easy operation and stable orientation.
Characteristics:
• Electromagnetic lock and balance technology ensure the easy operation and stable orientation.
• Cold light source is bright and even enough, which does no harm to tissues.
•Germanyimported Schott optics andApochromatic technology ensure clear field of view and high resolutions.
• Aspheric and BIOM added on objective could meet the demands of vitreo-retinal operations.
•The equipment is applied not only for ophthalmic operation, but also for neurosurgical, ENT, Cardio-Thoracic Surgical operations, etc.
•Optional accessories: oblique illumination, fundus aspheric lens and inversion（BIOM） lens.
Specifications:
|
Eye Piece Magnifications |
12.5×/18B |
|
Adjustable Diopter |
±6D |
|
Adjustable Range for Pupil Distance |
55mm～75mm |
|
Magnifications for Main Microscope |
4.6×～27×zoom magnification |
|
Diameter of Field |
F46～ F8.5mm |
|
Magnifications for Assistant Microscope |
6.2×、9.3×、14× |
|
Objective Focus |
f=200mm |
|
Optional Objectives |
f=250mm/300mm/350mm/400mm |
|
Working Distance |
195mm |
|
Maximal Resolution |
126LP/mm |
|
Illumination Source |
15V/150W,medical cold-reflection halogen lamp |
|
Illumination Type |
6°coaxial illumination,6°±2°coaxial illumination |
|
Maximal Illumination |
≥50000lx |
|
Filter |
UV&IR filter, yellow spot protection filter, redfree,GG435,GG475 |
|
Maximal Height for Microscope |
1710mm |
|
Reaching Radius of Arm |
1320mm |
|
AdjustableVerticalRange |
710mm~1310mm |
|
Fine Focusing Speed and Range |
≤2mm/s,50mm |
|
Speed for X/Y and Range |
≤2mm/s ,50mm×50mm, |
|
Arthrosis Fixation |
Electromagnetic Lock |
|
Input Voltage |
AC220V±10%/ 50Hz±1Hz、AC110V±10% / 60Hz±1Hz |
|
Power |
480VA |
|
Fuse |
AC250V T5.0AL (51S-050H)、AC125V T10.0AL (51S-0100L) |
|
Electrical Safety Standard |
Executive to GB9706.1-2007、Class I |
|
Packing Volume |
1.494m3,5cartons |
|
Total Weight |
302kg |
