MIC-ZJ6A is widely used in Orthopedics (hand surgical microscope, orthopedics, orthopedy, orthopedic), Hand Surgery and Plastic  for the anastomosis of capillaries and nerves. It allows simultaneous operation of two doctors, and supports image taking and video recording(hand surgical microscope, orthopedics, orthopedy, orthopedic)when equipped with CCD camera.  This an excellent medical (orthopedics, orthopedy, orthopedic) instrument for teaching and research.

2. Features: (orthopedics, orthopedy, orthopedic)

1. Continuous zoom optical system featuring clear image, strong stereo perception and broad field of view

2. Surgeon and assistant can observe at the same magnification ratio.

3. Objective lenses with different focus lengths allow three different working distances for surgeries (orthopedics, orthopedy, orthopedic) at various depths.

4. Coaxial light source of up to 80000Lx illumination has excellent performance for deep Operation(hand surgical microscope, orthopedics, orthopedy, orthopedic, operating microscope)

3 .Specifications:(orthopedics, orthopedy, orthopedic)

1) Binocular and same light route, magnification and field of view for two operators

2) Working distance: 200mm/250mm/300mm

3) Magnification: 5X, 25X motorized continuous zoom or manual zoom

4) Diameter of field of view 55 11mm

5) Eyepiece: 12.5X, 27.5mm Erfle wide angle eyepiece

6) Built-in micrometer: accuracy 0.1mm; length of measurement 10mm

7) Adjustment of eye distance: 5475mm

8) Visual acuity adjustment: ±6D

9) Motorized fine tuning: 40mm

10) Up-down adjusting range: 500mm

11) Maximum extending distance: 1200mm

12) Swing angle of cross arm:240º

13) Foot control X-Y plane mover: 40mm forward/back/left/right

14) Light source: 150W/15V coaxial light source

15) Power supply: 220V/50Hz

4. Options: (orthopedics, orthopedy, orthopedic)

  CCD Camera and connector for images taking and video recording
