Feature

Large diameter, wide eyes microscope optical fiber, Stereo sense is strong, high resolution, image is clear.

Secondary and primary mirror 90 degrees, with light Postures, manual consecutively variable times.

Aesthetical pleasingelectric foot control operation is more reliable and fine-tuning and convenient.

Specification



Item/Type

MIC-ZJ5B

Primary mirror

Secondary mirror

Microscope

Eyepiece

10.0 wide-angle

12.5 wide-angle

Pupil Distance

55~75mm

Diopter

±5 º(binocular)

Magnification

5X~20X

Field of view

10.5~50mm

Working distance

≥160mm

Fine focusing

40±10mm

Lighting system

Lighting form

Wide diameter optical fibers

Illumination

15V/150W halogen lamps

Control model

Four adjustment

Intensity

≥50000Lux

Power control

~220V50Hz

Frame part

Stretch arm length

1050mm

Up-down adjustment range

≥230mm

Base size

580 x560mm

Foot control switch

Electronic zoom
