MIC-CD5Aoperation microscope is the prince of the ‘little puppy’ kindred. It has only one binocular, (assistant binocular can be added if you need). But it’s the only simple one that has zoom lens and perfect depth of field. And the head of the microscope can stay in any angle you need. MIC-CD5Amicroscope was generally welcomed in E.N.T and Neurosurgery. And now we have developed the new MIC-CD5Awhich can be hung on the wall, very light and convenient.
Specification
|
Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens125mm. |
|
Binocular tube: high brightness 90°binocular tube |
|
Magnification: 6:1 zoom manual, magnification 2x~12.5x; field of view Φ95~Φ16mm |
|
Coaxial illumination: illumination diameter of light spot Φ70mm, illumination intensity 60000lux |
|
Objectives: f300mm(200mm,250mm,350mm,400mmetc ) |
|
Focusing: motorized, range +/-25mm, speed 33s/whole distance |
|
Maximum length of arm:1100mm |
|
New stand: swing angle of the carrier arm 0 ~300°,height from objective to floor730mm, Foot switch, waterproof |
|
Weight:107kg |
