Product specifications :

•Automatic and high intelligent, it can judge in time and solve automatically when it meet some small problems.

• prevent tissue form being injured, can automatically track feedback, remove some error in accumulating, position orderly, operate reliably.

•The users can set two program and choose any one according to different tissue.

•If the power is switched off suddenly, the machine can go on work and correct mistake automatically when the power switch on again.

•The LCD is make the communication between user and machine easily. The sterilization system can clean ,sterilize and exhaust the harmful air which exist from the evaporation of reagent .

Technical Data:

•Total containers: 12 (9 for reagent + 3 for medical paraffin)

•Station capacity:1000ml

•Processoring time: 0-99 Hrs

•Temperature range: 0~99℃

•Delay boot -strap time set arbitrarily in Any time you set .

•HMICraulic stop time: 20~120 seconds

•Remaining infiltration time:20 seconds

•tissue protective hydCraulic: in any bath from No 1 to No 9

•Normal voltage and frequency: AC200± 10%  50Hz ± 1Hz  500W± 10%

•Temperature of environment: 0~40℃

•Demension: 1200×680×600mm

•weight: 77kg
