MIC -335（Button Panel）Semi Automatic Microtome  AUOTMATIC MICROTOME

Product Specification:

• Adopted Germany motor drive ensure slice more precisely, more reliable and quiet.

• Special Blade carrier can use both of High profile blade and Low profile blade

• The LCD screen shows slice and trimming thickness ,section counter ,keyboard with controls for thickness, mode and speed

• Special function of specimen retraction which avoid the damage due to the attrition between sample and the back of knife so that the sectioning is more smooth and the life of the knife is more longer.

• The hand wheel can be locked in any position to ensure the sectioning as safe and convenient as possible

• The waste tray can be disassembled easily

• Sample orientation:8°along the X-Y-axis, rotate 360°

• Safety alarm system, overload protection function, sleep mode protection

• Universal cassette clamp and standard specimen clamp

Technical Data

• Section thickness range: 0- 100um

• Specimen feed speed 1250 μm/s

Setting values:

from 0-10 um in 1 um –increments

Form 10-20um in 2um-increments

Form 20-50 um in 5um-increments

Form 50-100um in 10 um-increments

• Trimming section thickness range :0-500um

• Horizontal specimen stroke :28 mm

• Vertical specimen stroke : 60mm

• Specimen retraction :12um

• Precision error: ± 5%

• Maximum section size: 50 × 45mm

• Dimension : 520 x 450 x 300mm

• Net weight：30kg
