The only full motorized model in the family of MIC operation microscope. It can focus motorized, zoom motorized and change the visual angle motorized. The visual angle can stay in any angle you need. It is very convenient for E.N.T and Neurosurgery.
Specification
|
Eyepieces: magnification 12.5x, pupil distance adjustable range55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens180mm. |
|
Binocular tube: 30°~90°variable angle binocular tube, add new pupil distance adjustment |
|
Magnification: 6:1 zoom, motorized, magnification 3x~16x; field of view Φ74~Φ12mm |
|
Coaxial assistant’s binocular tube: all direction circumvolve freely, magnification 3x~16x; field of view Φ74~Φ12mm |
|
Coaxial illumination: illumination diameter of light spot Φ78mm, illumination intensity 100000lux |
|
Objectives: f300mm(200mm,250mm,350mm,400mmetc ) |
|
Focusing: motorized, range +/-25mm, speed 33s/whole distance |
|
X-Y swing: The head can swing in X direction +/-45 °motorized, and in Y direction +90°,and can stop in any angle |
|
Maximum length of arm:1200mm |
|
New stand: swing angle of the carrier arm 0 ~300°,height from objective to floor,800mm, Foot switch, waterproof, 8 function steps |
|
Weight:164kg |
