1.3M pixel cmos digital video eyepiece
|
Sensor type |
Color CMOS |
||
|
Imaging sensor |
size |
1/3.2" |
|
|
Pixel size |
3.6μm×3.6μm |
||
|
Effective pixels |
1280x1024 |
||
|
Max resolution |
1280x1024 |
||
|
Sensitivity |
1.0V/lux-sec 550nm |
||
|
Dynamic Range |
>45dB |
||
|
Exposure Controls |
Automatic |
||
|
Gain Control |
Automatic |
||
|
White Balance |
One shot automatic control |
||
|
Image Frame Rate |
15fps @ 1280×1024; 15fps @ 1024×768; 15fps @ 800×600; 30fps @ 640×480. |
||
|
Control interface |
USB 2.0 |
||
|
Lens Mount |
Standard C/CS-mount |
||
|
Control Software Operating System |
Windows XP,Vista, 7 (32 bit and 64 bit) |
||
|
Power |
USB 2.0 supported |
||
|
Operating Temp |
0 to50 °C |
||
|
Dimensions |
33mm×33mm×55mm |
||
|
Weight |
90g |
||
|
Recommended PC Requirements |
Pentium 4, 1.3 GHz or higher |
||
|
512 MB RAM |
|||
|
200/500 MB hard drive free space or more |
|||
|
USB 2.0 Port |
|||
|
Windows XP,Vista, 7 |
|||
|
Application |
Education, Industrial microscopy, Live cell image, Medical, Semiconductor inspection, Metrology |
||
|
Packing Contents |
1.3MP Microscope Eyepiece Camera |
1 |
|
|
USB 2.0 cable |
1 |
||
|
CD with control software S-Viewer and driver |
1 |
||
|
Camera User Manual |
1 |
||
|
Optional accessories |
Reducing lens 0.45X |
||
|
Adapter ring (23.2mmto30mm) |
|||
|
Adapter ring (23.2mmto30.5mm) |
|||
2M pixel cmos digital video eyepiece
|
Sensor type |
Color CMOS |
||
|
Imaging sensor |
size |
1/3.2" |
|
|
Pixel size |
2.8μm×2.8μm |
||
|
Effective pixels |
1600x1200 |
||
|
Max resolution |
1600x1200 |
||
|
Sensitivity |
1.0V/lux-sec 550nm |
||
|
Dynamic Range |
>45dB |
||
|
Exposure Controls |
Automatic |
||
|
Gain Control |
Automatic |
||
|
White Balance |
One shot automatic control |
||
|
Image Frame Rate |
7.5fps @ 1600×1200; 7.5fps @ 1280×1024; 15fps @ 1024×768; 15fps @ 800×600; 30fps @ 640×480. |
||
|
Control interface |
USB 2.0 |
||
|
Lens Mount |
Standard C/CS-mount |
||
|
Control Software Operating System |
Windows XP,Vista, 7 (32 bit and 64 bit) |
||
|
Power |
USB 2.0 supported |
||
|
Operating Temp |
0 to50 °C |
||
|
Dimensions |
33mm×33mm×55mm |
||
|
Weight |
90g |
||
|
Recommended PC Requirements |
Pentium 4, 1.3 GHz or higher |
||
|
512 MB RAM |
|||
|
200/500 MB hard drive free space or more |
|||
|
USB 2.0 Port |
|||
|
Windows XP,Vista, 7 |
|||
|
Application |
Education, Industrial microscopy, Live cell image, Medical, Semiconductor inspection, Metrology |
||
|
Packing Contents |
2.0MP Microscope Camera |
1 |
|
|
USB 2.0 cable |
1 |
||
|
CD with control software S-Viewer and driver |
1 |
||
|
Camera User Manual |
1 |
||
|
Optional accessories |
Reducing lens 0.45X |
||
|
Adapter ring (23.2mmto30mm) |
|||
|
Adapter ring (23.2mmto30.5mm) |
|||
