Home > MicroscopePhoto Eyepiece > MIC-HD video eyepiece

0.35 M pixel video eyepiece cmos

HARDWARE CONFIGURATION

Image Pickup Device

APTINA CMOS color

Scan Mode

Progressive

Max. Resolution

640 x 480 (Approx. 350,000 Pixels)

Sensor Size (Diagonal)

1/4“ (3.58mm(H) x2.69mm(V), Diagonal4.48mm)

Pixel Size

5.6μm x 5.6μm

G Sensitivity

1.9v/lux-sec(550nm)

Dynamic Range

60dB

A/D Converter

8-Bit R.G.B

SN Ratio

45dB

Spectral Range

380-650nm (with IR-filter)

Video Format & Frame Rate

30fps @All Resolutions

Binning

N/A

Exposure

Electronic Rolling Snap(ERS), Auto

White balance

Auto

Color Rendering Technique

N/A

Peak Quantum Efficiency

N/A

Readout Noise

N/A

Extinction Ratio

N/A

Smear

N/A

Capture/Control API

DirectShow , Twain , VFW

Recording System

Still Picture and Movie

OPERATING ENVIRONMENT

Operating Temperature

-10~50

Storage Temperature

-20~60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB port

SOFTWARE ENVIRONMENT

Operating System

Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit)

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or higher

Memory:2GB or more

USB port:USB2.0 High-speed Port

Display:17" or larger

CD-ROM



1.3M pixel video eyepiece cmos

HARDWARE CONFIGURATION

Image Pickup Device

APTINA CMOS color

Scan Mode

Progressive

Max. Resolution

1280 x 1024 (Approx. 1,300,000 Pixels)

Sensor Size (Diagonal)

1/3“ (4.60mm(H) x3.70mm(V), Diagonal5.9mm)

Pixel Size

3.6μm x 3.6μm

G Sensitivity

1.0v/lux-sec(550nm)

Dynamic Range

71dB

A/D Converter

8-Bit R.G.B

SN Ratio

44dB

Spectral Range

380-650nm (with IR-filter)

Video Format & Frame Rate

7.5fps @1280 x 1024, 12.5fps @1024 x 768, 800 x 600, 30fps @Other Resolutions

Binning

N/A

Exposure

Electronic Rolling Snap(ERS), Auto

White balance

Auto

Color Rendering Technique

N/A

Peak Quantum Efficiency

N/A

Readout Noise

N/A

Extinction Ratio

N/A

Smear

N/A

Capture/Control API

DirectShow , Twain , VFW

Recording System

Still Picture and Movie

OPERATING ENVIRONMENT

Operating Temperature

-10~50

Storage Temperature

-20~60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB port

SOFTWARE ENVIRONMENT

Operating System

Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit)

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or higher

Memory:2GB or more

USB port:USB2.0 High-speed Port

Display:17" or larger

CD-ROM


2 M pixel video eyepiece cmos

HARDWARE CONFIGURATION

Image Pickup Device

APTINA CMOS color

Scan Mode

Progressive

Max. Resolution

1600 x 1200 (Approx. 2,000,000 Pixels)

Sensor Size (Diagonal)

1/3.2“ (4.73mm(H) x3.52mm(V), Diagonal5.90mm)

Pixel Size

2.8μm x 2.8μm

G Sensitivity

1.0v/lux-sec(550nm)

Dynamic Range

71dB

A/D Converter

8-Bit R.G.B

SN Ratio

42.3dB

Spectral Range

380-650nm (with IR-filter)

Video Format & Frame Rate

5fps @1600 x 1200, 7.5fps @1280 x 1024, 1280 x 960, 20fps @800 x 600, 30fps @ Other Resolutions

Binning

N/A

Exposure

Electronic Rolling Snap(ERS), Auto

White balance

Auto

Color Rendering Technique

N/A

Peak Quantum Efficiency

N/A

Readout Noise

N/A

Extinction Ratio

N/A

Smear

N/A

Capture/Control API

DirectShow , Twain , VFW

Recording System

Still Picture and Movie

OPERATING ENVIRONMENT

Operating Temperature

-10~50

Storage Temperature

-20~60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB port

SOFTWARE ENVIRONMENT

Operating System

Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit)

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or higher

Memory:2GB or more

USB port:USB2.0 High-speed Port

Display:17" or larger

CD-ROM


3 M pixel video eyepiece cmos

HARDWARE CONFIGURATION

Image Pickup Device

APTINA CMOS color

Scan Mode

Progressive

Max. Resolution

2048 x 1536 (Approx.3,200,000 Pixels)

Sensor Size (Diagonal)

1/2.7“ (4.506mm(H) x3.379mm(V), Diagonal5.632mm)

Pixel Size

2.2μm x 2.2μm

G Sensitivity

1.0v/lux-sec(550nm)

Dynamic Range

61dB

A/D Converter

8-Bit R.G.B

SN Ratio

43dB

Spectral Range

380-650nm (with IR-filter)

Video Format & Frame Rate

3fps @2048 x 1536, 5fps @1600 x 1200, 7.5fps @1280 x 1024, 30fps @Other Resolutions

Binning

N/A

Exposure

Electronic Rolling Snap(ERS), Auto

White balance

Auto

Color Rendering Technique

N/A

Peak Quantum Efficiency

N/A

Readout Noise

N/A

Extinction Ratio

N/A

Smear

N/A

Capture/Control API

DirectShow , Twain , VFW

Recording System

Still Picture and Movie

OPERATING ENVIRONMENT

Operating Temperature

-10~50

Storage Temperature

-20~60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB port

SOFTWARE ENVIRONMENT

Operating System

Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit)

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or higher

Memory:2GB or more

USB port:USB2.0 High-speed Port

Display:17" or larger

CD-ROM


5 M pixel video eyepiece cmos

HARDWARE CONFIGURATION

Image Pickup Device

APTINA CMOS color

Scan Mode

Progressive

Max. Resolution

2592 x 1944 (Approx.5,200,000 Pixels)

Sensor Size (Diagonal)

1/2.5“ (5.70mm(H) x4.28mm(V), Diagonal7.13mm)

Pixel Size

2.2μm x 2.2μm

G Sensitivity

0.53v/lux-sec(550nm)

Dynamic Range

66.5dB

A/D Converter

8-Bit R.G.B

SN Ratio

40.5dB

Spectral Range

380-650nm (with IR-filter)

Video Format & Frame Rate

2fps @2592 x 1944, 3fps @2048 x 1536, 5fps @1600 x 1200, 7.5fps @1280x1024, 30fps @Other Resolutions

Binning

N/A

Exposure

Electronic Rolling Snap(ERS), Auto

White balance

Auto

Color Rendering Technique

N/A

Peak Quantum Efficiency

N/A

Readout Noise

N/A

Extinction Ratio

N/A

Smear

N/A

Capture/Control API

DirectShow , Twain , VFW

Recording System

Still Picture and Movie

OPERATING ENVIRONMENT

Operating Temperature

-10~50

Storage Temperature

-20~60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB port

SOFTWARE ENVIRONMENT

Operating System

Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit)

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or higher

Memory:2GB or more

USB port:USB2.0 High-speed Port

Display:17" or larger

CD-ROM
