MIC MTD series fixed monocular video microscope objectives, according to magnification, working distance, coaxial illuminator, non-coaxial illuminator, optical path turn 90°. It has almost one hundred scales and types, own best assortment product of monocular video microscope objectives inChina. It includes Single Magnification Video Optical Systems, Lathe tool--setting Inclined Eye tube Microscope, Exchangeable Objectives Double Magnification Video Optical Systems, MTDP Infinite Farness Lens Monocular Video Optical Systems. It can be applied in electric equipments, semiconductor test, tin-spot test, printing paste test, wafer, LCD test and the similar uses.
Main technology Specifications:
MTD series have hundreds kinds of products, please look at the below list:MTD series fixed magnification monocular video microscope objectives model specification gathering(near hundred kinds)：
MTD series fixed magnification monocular video microscope objectives model specification gathering (near hundred kinds):
|
Model |
Objective magnification |
Working distance (mm) |
Total magnification |
Field of video (mm) |
NA |
Depth of field |
Resolution |
|
|
1/3"、9" |
1/3"、17" |
|||||||
|
MTD01-156 |
0.1X |
155 |
4X |
7.2X |
48X36 |
0.008 |
50mm |
42μm |
|
MTD02-140 |
0.2X |
140 |
8X |
14.4X |
24X18 |
0.015 |
13.5mm |
23μm |
|
MTD03-120 |
0.3X |
120 |
12X |
21.6X |
16X12 |
0.045 |
2.96mm |
7.5μm |
|
MTD03C-168SA |
168 |
0.026 |
5.1mm |
12.9μm |
||||
|
MTD03-170 |
170 |
0.027 |
4.9mm |
12.4μm |
||||
|
MTD03C-170 |
170 |
0.026 |
5.1mm |
12.9μm |
||||
|
MTD3.5-198 |
0.35X |
198 |
14X |
25.2X |
13.7X11.3 |
0.03 |
3.8mm |
11.2μm |
|
MTD04-100 |
0.4X |
100 |
16X |
28.8X |
12X9 |
0.059 |
1.7mm |
5.8μm |
|
MTD04-150 |
150 |
0.042 |
2.4mm |
8.2μm |
||||
|
MTD04-660 |
660 |
0.0134 |
7.46mm |
25μm |
||||
|
MTD05C-60 |
0.5X |
60 |
20X |
36X |
9.6X7.2 |
0.09 |
888.9μm |
3.7μm |
|
MTD06-150 |
0.6X |
149.1 |
24X |
43.2X |
8X6 |
0.042 |
1.6mm |
8.2μm |
|
MTD06C-150 |
150 |
0.042 |
1.6mm |
8.2μm |
||||
|
MTD06C-170 |
170 |
0.025 |
2.67mm |
13.4μm |
||||
|
MTD06C-188 |
188.5 |
0.046 |
1.45mm |
7.3μm |
||||
|
MTD6.5C-70RA |
0.7X |
70 |
28X |
50.4X |
6.9X5.1 |
0.070 |
879.1μm |
4.79μm |
|
MTD07-75RA |
0.7X |
75 |
28X |
50.4X |
6.9X5.1 |
0.052 |
1.1mm |
6.5μm |
|
MTD07-100 |
100 |
0.048 |
1.2mm |
6.8μm |
||||
|
MTD07C-100 |
100 |
0.048 |
1.2mm |
6.8μm |
||||
|
MTD08C-150 |
0.8X |
150 |
32X |
57.6X |
6X4.5 |
0.042 |
1.19mm |
8μm |
|
MTD10-40 |
1.0X |
40 |
40X |
72X |
4.8X3.6 |
0.105 |
381μm |
3.2μm |
|
MTD10C-65S |
65 |
0.071 |
563.4μm |
4.72μm |
||||
|
MTD10-70 |
69.4 |
0.047 |
588.2μm |
4.9μm |
||||
|
MTD10C-70 |
69.4 |
0.047 |
588.2μm |
4.9μm |
||||
|
MTD10C-98RA |
98 |
0.047 |
851.1μm |
7.1μm |
||||
|
MTD10-100 |
100 |
0.07 |
571μm |
4.8μm |
||||
|
MTD10C-100 |
100 |
0.07 |
571μm |
4.8μm |
||||
|
MTD10C-110S |
110 |
0.057 |
701.8μm |
5.9μm |
||||
|
MTD10C-110SA |
110 |
0.0525 |
761.9μm |
6.4μm |
||||
|
MTD10-148 |
148 |
0.046 |
869.6μm |
7.29μm |
||||
|
MTD10C-170SA |
170 |
0.033 |
1.21mm |
10.2μm |
||||
|
MTD10C-180 |
179 |
0.0273 |
1.47mm |
12.3μm |
||||
|
MTD10-190 |
190 |
0.025 |
1.6mm |
13.4μm |
||||
|
MTD12.5C-110 |
1.25X |
110 |
50X |
90X |
3.8X2.9 |
0.065 |
571μm |
6μm |
|
MTD12.5C-150 |
150 |
0.041 |
780μm |
8μm |
||||
|
MTD12.5-150 |
150 |
0.041 |
780μm |
8μm |
||||
|
MTD12.5C-150S |
150 |
0.041 |
780μm |
8μm |
||||
|
MTD12.5C-175 |
175 |
0.036 |
889μm |
9.2μm |
||||
|
MTD15-90 |
1.5X |
90 |
60X |
108X |
3.2X2.4 |
0.06 |
444μm |
5.6μm |
|
MTD15C-98RA |
98 |
0.047 |
567.4μm |
7.1μm |
||||
|
MTD15C-120 |
120 |
0.054 |
493.8μm |
6.2μm |
||||
|
MTD15-150 |
150 |
0.042 |
634.9μm |
8.0μm |
||||
|
MTD15C-150RA |
150 |
0.042 |
634.9μm |
8.0μm |
||||
|
MTD15C-250 |
250 |
0.035 |
761.9μm |
9.6μm |
||||
|
MTD17-93RA |
1.7X |
93 |
68X |
122.4X |
2.8X2.1 |
0.044 |
534.8μm |
7.63μm |
|
MTD18C-110 |
1.8X |
110 |
72X |
129.6X |
2.7X2 |
0.057 |
389.9μm |
5.9μm |
Optional stand and base stage：
MTD series fixed magnification monocular video microscope objectives model specification gathering (near hundred kinds):
|
Model |
Objective magnification |
Working distance (mm) |
Magnification |
Field of video (mm) |
NA |
Depth of field |
Resolution |
|
|
1/3"、9" |
1/3"、17" |
|||||||
|
MTD20-50 |
2.0X |
49.5 |
80X |
144X |
2.4X1.8 |
0.12 |
166.7μm |
2.8μm |
|
MTD20-65S |
65 |
0.073 |
274μm |
4.6μm |
||||
|
MTD20C-70 |
70 |
0.08 |
250μm |
4.2μm |
||||
|
MTD20C-80RA |
80 |
0.081 |
246.9μm |
4.1μm |
||||
|
MTD20C-110 |
110 |
0.061 |
330μm |
5.6μm |
||||
|
MTD20C-130 |
130.5 |
0.0486 |
411.5μm |
6.9μm |
||||
|
MTD20-150 |
150 |
0.043 |
470μm |
8μm |
||||
|
MTD20C-150 |
150 |
0.043 |
470μm |
8μm |
||||
|
MTD20C-170A |
169.3 |
0.05 |
400μm |
6.7μm |
||||
|
MTD20C-170 |
169.3 |
0.05 |
400μm |
6.7μm |
||||
|
MTD20C-185SA |
185 |
0.037 |
540.5μm |
9.1μm |
||||
|
MTD25C-70A |
2.5X |
70 |
100X |
180X |
1.9X1.4 |
0.07 |
185μm |
3.8μm |
|
MTD25-100 |
100 |
0.07 |
229μm |
4.8μm |
||||
|
MTD25C-100RA |
100 |
0.07 |
229μm |
5.8μm |
||||
|
MTD25-110S |
110 |
0.058 |
275.9μm |
6.2μm |
||||
|
MTD25C-150 |
150 |
0.058 |
275.9μm |
5.8μm |
||||
|
MTD25-175 |
175 |
0.05 |
320μm |
6.7μm |
||||
|
MTD30C-33RA |
3.0X |
|
120X |
216X |
1.6X1.2 |
0.077 |
173.2μm |
4.36μm |
|
MTD30C-60 |
60 |
0.07 |
148μm |
3.7μm |
||||
|
MTD30-80 |
80 |
0.095 |
140.4μm |
3.53μm |
||||
|
MTD30-90 |
90 |
0.07 |
190μm |
4.7μm |
||||
|
MTD30-99 |
99 |
0.072 |
185.2μm |
4.66μm |
||||
|
MTD30-100 |
100 |
0.068 |
196.1μm |
4.9μm |
||||
|
MTD30C-115 |
115 |
0.075 |
177.8μm |
4.5μm |
||||
|
MTD35C-65 |
3.5X |
56 |
140X |
252X |
1.4X1.0 |
0.094 |
120μm |
3.6μm |
|
MTD40C-135 |
4.0X |
135 |
160X |
288X |
1.2X0.9 |
0.064 |
156.3μm |
5.2μm |
|
MTD50-32 |
5.0X |
32 |
200X |
360X |
1.0X0.7 |
0.25 |
32μm |
1.3μm |
|
MTD50C-90RA |
90 |
0.07 |
114μm |
4.8μm |
||||
|
MTD80C-80 |
8.0X |
80 |
320X |
576X |
0.6X0.45 |
0.102 |
49μm |
3.3μm |
|
MTD(08-20)C-80 |
0.8X/2.0X |
80 |
32X/80X |
57.6X/144X |
6X4.5/2.4X1.8 |
0.062 |
800/320 |
5.5/5.4 |
|
MTD(08-25)C-70 |
0.8X/2.5X |
56 |
32X/100X |
57.6X/180X |
6X4.5/1.9X1.4 |
0.069/0.08 |
700/200 |
5/4.2 |
|
MTD(08-25)C-70RA |
70 |
0.069/0.08 |
700/200 |
5/4.2 |
||||
|
MTD(08-40)C-60 |
0.8X/4.0X |
56 |
32X/160X |
57.6X/290X |
6X4.5/1.2X0.9 |
0.086/0.092 |
570/110 |
4/3.6 |
|
MTD(20-35)C-80 |
2.0X/3.5X |
80 |
80X/140X |
144X/252X |
2.4X1.8/1.4X1.0 |
0.076/0.082 |
250/140 |
4.6/4.1 |
|
Model |
Objective magnification |
Working distance (mm) |
Field of video (mm) |
NA |
Resolution(μm) |
|
MTD15-70/42° |
1.5X |
70 |
Φ15.3 |
0.043 |
7.8 |
|
MTD20-110/42° |
2.0X |
110 |
Φ11.5 |
0.062 |
5.4 |
|
MTD20-200/42° |
2.0X |
70 |
Φ11.5 |
0.043 |
7.8 |
|
MTD30-90/42° |
3.0X |
90 |
Φ7.7 |
0.075 |
4.5 |
Note:
1. The depth of field is the value
of parsing images if you use 1/2" CCD camera and monitor of level 320
line.(imaging surface concessional confusion circumference: 40μm)
2. Resolution is the theory
resolution of wavelength in 550nm.
3. The largest compatible CCD:
1/2"
4. Install dimension: C-mount, the
whorl is 1 inch 32 button.
5. In the line of total
magnification, 1/3" is expressed CCD camera's specifications, 9"、17" is expressed monitor's screen dimensions.
1/3"、9" is expressed the total
magnification of MTD series fixed magnification monocular video microscope
objective in 1/3" CCD camera and 9" monitor.
