Specification |
||||||
|
Eyepiece |
Wide field WF10X(field number:µ22mm) |
|||||
|
Centering telescope |
||||||
|
Infinity plan achromatic objective |
Objective |
PLL 10X0.25 Work distance:4.3mm,Cover glass thickness:1.2mm. |
||||
|
PLL 20X0.40 Work distance:8.0mm,Cover glass thickness:1.2mm. |
||||||
|
PLL 40X0.60 Work distance:3.5mm,Cover glass thickness:1.2mm. |
||||||
|
Phase Contrast Objective |
PLL 10X0.25 PHP2 Work distance:4.3mm,Cover glass thickness:1.2mm. |
|||||
|
PLL 20X0.40 PHP2 Work distance:8.0mm,Cover glass thickness:1.2mm. |
||||||
|
PLL 40X0.60 PHP2 Work distance:3.5mm,Cover glass thickness:1.2mm. |
||||||
|
Eyepieces tube |
Inclination angle is 45˚ and interpupillary distance is 53~75mm. |
|||||
|
Epi-fluorescent illumination system |
Power supply unit, 110V or 230V can be selected. |
|||||
|
100W/DC Mercury lamp is 100W/DC |
||||||
|
Fluorescent filters |
||||||
|
Group |
Type |
Wavelength of excitation light |
Wavelength of emitted light |
|||
|
UV+V |
Ultraviolet light (UV) |
330nm~400nm |
425nm |
|||
|
Violet light (V) |
395nm~415nm |
455nm |
||||
|
B+G |
Blue light (B) |
420nm~485nm |
515nm |
|||
|
Green light (G) |
460nm~550nm |
590nm |
||||
|
Focus system |
Coaxial coarse/fine focus, with tension adjustable and up stop, minimum division of fine focusing is 2μm. |
|||||
|
Nosepiece |
Quintuple nosepiece |
|||||
|
Stage |
Fixed stage overall size is 227mmX208mm |
|||||
|
Glass rotundity stage overall size is Ф118mm |
||||||
|
Mechanical moving device, moving range is77mm(longitudinal)X114mm(transverse) |
||||||
|
Culture dish holder 1 |
Inside locating slot size:86mm(W)X129.5mm(L), optional with a circular culture dish Ф87.5mm |
|||||
|
Culture dish holder 2 |
Inside locating slot size:34mm(W)X77.5mm(L), optional with a circular culture dish Ф68.5mm |
|||||
|
Culture dish holder 3 |
Inside locating slot size:57mm(W)X82mm(L) |
|||||
|
Transmitted illumination system |
Turnplate phase contrast condenser, working distance is55mm |
|||||
|
6V30W halogen, brightness enable control |
||||||
|
Frosted glass and blue , green filter |
||||||
Optional accessories
|
Eyepiece |
10XDividing eyepiece(field number:¦µ22mm) 0.10mm/Div |
1122010 |
|
Objective |
Infinity plan achromatic objective PL 5X/0.12 W.D26.1 |
2060105 |
|
Infinity plan achromatic objective PL 20X/0.40 W.D8.8 |
2060120 |
|
|
Infinity plan achromatic objective PL 60X/0.8 (Spring) W.D0.46 |
2060160 |
|
|
Nosepiece |
Sextupe (Backward ball bearing inner locating) |
033001 |
|
CCD adapter |
0.4X |
810001 |
|
0.5X |
810004 |
|
|
1X |
810002 |
|
|
0.5Xwith dividing0.1mm/Div |
810003 |
|
|
Camera |
DV-1(with USB and Video output) |
800001 |
|
DV-2(with USB output) |
800003 |
|
|
DV-3(with Video output) |
800005 |
|
|
Digital camera adapter |
CANON(EF), NIKON(F) |
820001 |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice
