Item |
A-F12i |
A-F13i |
Order NO. |
|
||
A-F1 Frame |
One-piece construction from arm to base. |
● |
● |
A-F1 |
|
|
Optics |
UCIS Infinity Independent Achromatic Optical Design |
● |
● |
|
||
Electric |
110/220V,50/60Hz (Order number DQ3 or DQL1 are included) |
● |
● |
|
||
Focusing |
Coaxial coarse and fine focusing knob, height adjustable. |
● |
● |
|
||
Condenser Adjust Unit |
|
● |
● |
|
||
Seidentopf Observation Tube |
Binocular Tube, Interpupillary distance 52-75mm,30°inclined,360° rotateable,diopter adjustable. |
● |
|
MS2 |
|
|
Binocular Tube, Interpupillary distance 48-75mm,30°inclined,360° rotateable,diopter adjustable. |
○ |
|
MS2A |
|
||
Trinocular Tube, Interpupillary distance 52-75mm,30°inclined,trinocular light is split 20/80 by a high quality prism,diopter adjustable. |
|
● |
MT2 |
|||
Trinocular Tube, Interpupillary distance 48-75mm,30°inclined,trinocular light is split 20/80 by a high quality prism,diopter adjustable. |
|
○ |
MT2A |
|||
Plan Eyepiece |
WF10X/20, High eye-point up to21mm. |
●● |
●● |
E1020PA |
|
|
WF10X/22, High eye-point up to21mm. |
○○ |
○○ |
E1022PC |
|
||
WF16X/14 |
○○ |
○○ |
E1614WB |
|
||
WF10X/20(Pointer), High eye-point up to21mm. |
○ |
○ |
E1020GA |
|
||
WF10X/22(Pointer), High eye-point up to21mm. |
○ |
○ |
E1022GC |
|
||
Reticule Eyepiece: CROSSWF10X/20 |
○ |
○ |
E1020RA |
|
||
Reticule Eyepiece: CROSSWF10X/22 |
○ |
○ |
E1022RC |
|
||
Centering Telescope |
CTE |
○ |
○ |
CTE |
|
|
Infinity Plan Objectives |
Plan 2X/0.06 ∞/-, WD3.55 |
○ |
○ |
WB-P4A |
|
|
Plan 4X/0.10 ∞/-,WD12.31 |
● |
● |
WB-P4C |
|
||
Plan 10X/0.25 ∞/0.17,WD5.03 |
● |
● |
WB-P10C |
|
||
Plan 20X/0.40 ∞/0.17,WD2.71 |
○ |
○ |
WB-P20C |
|
||
Plan 40X/0.65 ∞/0.17, WD0.72 (Spring) |
● |
● |
WB-P40C |
|
||
Plan 60X/0.80 ∞/0.17, WD0.69 (Spring) |
○ |
○ |
WB-P60C |
|
||
Plan 100X/1.25 ∞/0.17, WD0.17 (Spring,Oil) |
● |
● |
WB-P100C |
|
||
Infinity Plan Phase-Contrast (positive or negative) Objectives |
PH Plan 10X/0.25 ∞/0.17,WD5.03 |
○ |
○ |
WB-PPHp10C/WB-PPHn10C |
|
|
PH Plan 20X/0.40 ∞/0.17,WD2.71 |
○ |
○ |
WB-PPHp20C/WB-PPHn20C |
|
||
PH Plan 40X/0.65 ∞/0.17,WD0.72 (Spring) |
○ |
○ |
WB-PPHp40C/WB-PPHn40C |
|
||
PH Plan 60X/0.80 ∞/0.17, WD0.69 (Spring) |
○ |
○ |
WB-PPHp60C/WB-PPHn60C |
|
||
PH Plan 100X/1.25 ∞/0.17,WD0.17 (Spring,Oil) |
○ |
○ |
WB-PPHp100C/WB-PPHn100C |
|
||
Phase-Contrast Slide |
10X PH |
○ |
○ |
PCB-PPH10C |
|
|
20X PH |
○ |
○ |
PCB-PPH20C |
|
||
40X PH |
○ |
○ |
PCB-PPH40C |
|
||
60X PH |
○ |
○ |
PCB-PPH60C |
|
||
100X PH |
○ |
○ |
PCB-PPH100C |
|
||
Condenser |
Multi-Purpose Phase-contrast Condenser: NA:1.25,Phase-contrast observation from 10X to 100X and Dark-field observation from 10X to 40X is allowed |
○ |
○ |
JG40 |
|
|
Abbe condenser: NA 1.25, with iris diaphragm, with socket to accommodate PH-slide. Condenser center adjustable, color-coded diaphragm scale markings cooresponded with the objectives of different powers. |
● |
● |
JG3 |
|
||
Dark Condenser(Dry) |
○ |
○ |
JG10 |
|
||
Stage |
Mechanical Stage: 156x138mmplatform, with X/Y travel of 76x54mmby low-positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide. |
● |
● |
ZT2 |
|
|
Rackless Mechanical Stage: 179(205)x175mmplatform, with X/Y travel of 75x50mmby low-positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide. |
○ |
○ |
ZT2A |
|
||
Revolving Nosepiece |
quadruple, inward facing. |
● |
● |
ZQ480 |
|
|
quintuple, inward facing |
○ |
○ |
ZQ580 |
|
||
Illumination Kohler |
With field diaphragm |
● |
● |
KL3A |
|
|
Electrical Parts |
For 6V/20W Halogen Bulb: Input: 100-240V~0.5A, 47-63Hz, Output:6V3.4A, Fuse:3.15A, 250V, F ф5×20mm, Halogen Bulb Socket: G4 |
● |
● |
DQ3 |
|
|
For 6V/30WHalogen Bulb: Input: 100-240V~0.5A, 47-63Hz, Output:6V3.4A, Fuse:3.15A, 250V, F ф5×20mm, Halogen Bulb Socket: G4 |
○ |
○ |
DQ2A |
|
||
For 3W LED Bulb |
○ |
○ |
DQL1 |
|
||
C-Mount |
1X |
|
○ |
SX3 |
|
|
0.5X |
|
● |
SX2 |
|
||
0.25X |
|
○ |
SX4 |
|
||
Digital Camera Adapter |
SD2 |
|
○ |
SD2 |
|
|
Digital Camera Joint |
(Please advice your digital camera model in advance) |
|
○ |
SDK |
|
|
Filter |
Blue |
● |
● |
LA2-0011 |
|
|
Green |
○ |
○ |
LU2-0011 |
|
||
Yellow |
○ |
○ |
LH2-0011 |
|
||
Grass Glass |
○ |
○ |
LB2-0011 |
|
||
Filter Holder |
Filter Holder: (Attached to the Kholer) for more than one filter. |
● |
● |
LA1-0071 |
|
|
Polarization kits |
Analyzer Slide |
○ |
○ |
PQ1 |
|
|
Polarizer Slide |
○ |
○ |
PY1 |
|
||
Reflected Flourescence Attachment |
DC Hg Florecence Lamphouse 100W |
○ |
○ |
DX1 |
|
|
Mercury lamp 100W(Made inChina) |
● |
● |
BZ-0022H |
|
||
Mercury lamp 100W(Osram) |
○ |
○ |
BZ0022I |
|
||
Filter Turret |
● |
● |
LSS2 & LST1 |
|
||
UV Shield |
● |
● |
LST1-5000 |
|
||
DC Hg Power Source House 100W |
● |
● |
DYX3 |
|
||
Fuse 250V/5AΦ5X20 |
●●● |
●●● |
BZ-0023A |
|
||
UV Excitaion Filter (I Grade) |
○ |
○ |
YGMKI-UV |
|
||
V Excitation Filter (I-Grade) |
○ |
○ |
YGMKI-V |
|
||
B Excitation Filter (I-Grade) |
○ |
○ |
YGMKI-B |
|
||
G Excitation Filter (I-Grade) |
○ |
○ |
YGMKI-G |
|
||
UV Excitaion Filter (C-Grade) |
○ |
○ |
YGMKC-UV |
|
||
V Excitation Filter (C-Grade) |
○ |
○ |
YGMKC-V |
|
||
B Excitation Filter (C-Grade) |
○ |
○ |
YGMKC-B |
|
||
G Excitation Filter (C-Grade) |
○ |
○ |
YGMKC-G |
|
||
Illumiation Bulb |
6V20W Osram Halogen Bulb |
● |
● |
BZ-0022A |
|
|
6V30W Osram Halogen Bulb |
○ |
○ |
BZ-0022B |
|
||
3W LED Bulb |
○ |
○ |
DQL1-1000 |
|
||
Immerse Oil |
8ml |
● |
● |
BZ-0027 |
|
|
Allen Screw Driver |
φ2mm |
● |
● |
BZ2-0018 |
|
|
Power Line |
1.8m, CE certified |
● |
● |
BZ-0021 |
|
|
Package |
Inner package: foam, plastic bag; Out Package: Carton |
● |
● |
BZ3-0011A |
|
|
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
