Items

Spec and Parameter

XSZ-HY1

XSZ-HY2

Order No.

Main body

●

●

MS50Xb

Eyepiece

Plan 10X-18

●●

●●

EP10a

Plan 16X-10

●●

●●

EP16a

S-plan objective

S-plan 4X/0.10

●

●

B-OSPr4

S-plan 10X/0.25

●

●

B-OSPr10

S-plan 40X/0.65

●

●

B-OSPr40a

S-plan 100X/1.25(Oil)

●

●

B-OSPor100

Plan-objective

Plan 4X/0.10

○

○

B-OPr4

Plan 10X/0.25

○

○

B-OPr10

Plan 40X/0.65

○

●

B-OPr40

Fluorescent objectives

25/0.65

●

●

B-OFr25

40/1(Glycerin)

●

●

B-OFor40

100/1.25(Glycerin)

●

●

B-OFor100

Head

Seidentopf Binocular Head Inclined 30°, and Rotatable 360°, Interpupilary Distance: 55-75mm

●

●

TTR01

Nosepiece

Quadruple Nosepiece

●

●

R03

Quintuple Nosepiece

○

○

7X.2

Stage

Size: 160x135mmMoving Range: 76x50mm

●

●

S20

Condenser

Abbe N.A. 1.25

●

●

C05

Epi-fluorescent Attachment

Epi-fluorescent Main Body (B,G)

●

●

FD02

200W Mercury Lamp House

●

31X.2

Power Supply Case of 200W Mercury Lamp

●

31.X.3

100W Mercury Lamp House

●

LH08

DC-Power Supply Case of 100W Mercury Lamp

●

PS-2

Centering Device

○

○

CU61

Collecting Lens

●

●

B06.4a

Base

Tungsten halogen lamp：6V/20W

Fuse tube:2AΦ5X20

Input: AC85V～265V, 50Hz～60Hz

Output: DC 1.4V-6V, maximum power 6V 20W

●

●

B06a

Photo Attachment

Photo Adaptor (2.5X, 4X, 6.3X)

○

○

MP03+EPHn4/2.5/6.3

TV and Video Attachment

C-mount Adaptor, Color or Black and White Monitor, CCD Camera

○

○

TV02

Digital Photo Attachment

Match withOlympusserials camera

○

○
