Model No |
Sensor |
Sensor |
Color |
Sensor |
Pixel |
Shutter |
Pixel |
Resolution |
Data |
Frame |
Lens |
|
M-3507M |
CMOS |
- |
Mono |
2/3” |
3.45μm |
Global |
5MP |
2448 x 2048 |
U3B3.0 |
35FPS |
C / CS Mount |
|
M-3507 |
CMOS |
- |
Color |
2/3” |
3.45μm |
Global |
5MP |
2448 x 2048 |
U3B3.0 |
35FPS |
C / CS Mount |
|
M-3630 |
CMOS |
- |
Color |
1/1.8” |
2.4μm |
Rolling |
6.3MP |
3072 x 2048 |
U3B3.0 |
30FPS |
C / CS Mount |
|
M-3880M |
CMOS |
- |
Mono |
2/3” |
2.5μm |
Rolling |
8MP |
3968 × 2232 |
USB3.0 |
22FPS |
C / CS Mount |
|
M-3880 |
CMOS |
- |
Color |
2/3” |
2.5μm |
Rolling |
8MP |
3968 × 2232 |
USB3.0 |
22FPS |
C / CS Mount |
|
M-31200M |
CMOS |
- |
Mono |
1” |
3.1μm |
Rolling |
12MP |
4096 x 3072 |
U3B3.0 |
15FPS |
C / CS Mount |
|
M-31200 |
CMOS |
- |
Color |
1” |
3.1μm |
Rolling |
12MP |
4096 x 3072 |
U3B3.0 |
15FPS |
C / CS Mount |
|
M-32000 |
CMOS |
- |
Color |
1” |
2.4μm |
Rolling |
20MP |
5472 × 3678 |
U3B3.0 |
9.6FPS |
U3B3.0 |
|
Model |
M-3507M-H |
|
Pixels |
5MP(Mono) |
|
Sensor Size |
2/3" CMOS |
|
Pixel Size |
3.45μm x 3.45μm |
|
Max Resolution |
2448(H)x2048(V) |
|
Frame rate |
39fps |
|
BIN |
2x2 |
|
ROI |
Any ROI |
|
Shutter |
Global shutter |
|
Exposure Time |
46μs ～ 10s |
|
Spectral Range (nm) |
380nm~1050nm |
|
Image data format |
8bit/12bit RAW |
|
Working Mode |
Continuous output/software trigger/hardware trigger |
|
Software Interface |
USB3.0 VisionV1.0 GENICAM/DirectShow/Twain |
|
On-board buffer |
64MB |
|
Exposure |
Manual / Auto/ Area Exposure |
|
White Balance |
Manual/One-time/Automatic/Area (Only for color camera) |
|
Image processing |
Speed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/ 2D,3D Noise Reduction/（Saturation only for color camera） |
|
User Memory |
32K bit |
|
Product ID |
user-defined |
|
Systems |
Windows XP (32bit);Windows 7 (32bit/64bit);Windows 8 (32bit/64bit);Windows 8.1 (32bit/64bit)/Window 10(64bit) |
|
Data Interface |
USB3.0 Type-B |
|
Transmission Distance |
5 meters |
|
Trigger Port |
6PIN Connector |
|
Rated Power(W) |
<2.0W |
|
Working Temperature |
0~50℃ |
|
Working Humidity |
10~90%RH( No condensation) |
|
lens Mount |
C / CS Mount |
|
Product Size (mm) |
44mm * 44mm * 39mm（Exclude lens extension ring） |
|
Weight |
Approx 140g |
|
Certificate |
CE/ROHS |
|
Model |
M-3507-H |
|
Pixels |
5MP(color) |
|
Sensor Size |
2/3" CMOS |
|
Pixel Size |
3.45μm x 3.45μm |
|
Max Resolution |
2448(H)x2048(V) |
|
Frame rate |
39fps |
|
BIN |
2x2 |
|
ROI |
Any ROI |
|
Shutter |
Global shutter |
|
Exposure Time |
46μs ～ 10s |
|
Spectral Range (nm) |
380nm~650nm |
|
Image data format |
8bit/12bit RAW |
|
Working Mode |
Continuous output/software trigger/hardware trigger |
|
Software Interface |
USB3.0 VisionV1.0 GENICAM/DirectShow/Twain |
|
On-board buffer |
64MB |
|
Exposure |
Manual / Auto/ Area Exposure |
|
White Balance |
Manual/One-time/Automatic/Area (Only for color camera) |
|
Image processing |
Speed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/ 2D,3D Noise Reduction/（Saturation only for color camera） |
|
User Memory |
32K bit |
|
Product ID |
user-defined |
|
Systems |
Windows XP (32bit);Windows 7 (32bit/64bit);Windows 8 (32bit/64bit);Windows 8.1 (32bit/64bit)/Window 10(64bit) |
|
Data Interface |
USB3.0 Type-B |
|
Transmission Distance |
5 meters |
|
Trigger Port |
6PIN Connector |
|
Rated Power(W) |
<2.0W |
|
Working Temperature |
0~50℃ |
|
Working Humidity |
10~90%RH( No condensation) |
|
lens Mount |
C / CS Mount |
|
Product Size (mm) |
44mm * 44mm * 39mm（Exclude lens extension ring） |
|
Weight |
Approx 140g |
|
Certificate |
CE/ROHS |
|
Model |
M-35600-H |
|
Pixels |
6.3MP(color) |
|
Sensor Size |
2/1.8" CMOS |
|
Pixel Size |
2.4μm x 2.4μm |
|
Max Resolution |
3072(H)x2048(V) |
|
Frame rate |
30fps |
|
BIN |
2x2/3x3 |
|
ROI |
Any ROI |
|
Shutter |
Rolling shutter |
|
Exposure Time |
41μs ～ 16s |
|
Spectral Range (nm) |
380nm~650nm |
|
Image data format |
8bit/12bit |
|
Working Mode |
Continuous output/software trigger |
|
Software Interface |
DirectShow/Twain |
|
On-board buffer |
64MB |
|
Exposure |
Manual / Auto/ Area Exposure |
|
White Balance |
Manual/One-time/Automatic/Area (Only for color camera) |
|
Image processing |
Speed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/ 2D,3D Noise Reduction/（Saturation only for color camera） |
|
User Memory |
32K bit |
|
Product ID |
user-defined |
|
Systems |
Windows XP (32bit);Windows 7 (32bit/64bit);Windows 8 (32bit/64bit);Windows 8.1 (32bit/64bit)/Window 10(64bit) |
|
Data Interface |
USB3.0 Type-B |
|
Transmission Distance |
5 meters |
|
Trigger Port |
N/A |
|
Rated Power(W) |
<2.0W |
|
Working Temperature |
0~50℃ |
|
Working Humidity |
10~90%RH( No condensation) |
|
lens Mount |
C / CS Mount |
|
Product Size (mm) |
44mm * 44mm * 39mm（Exclude lens extension ring） |
|
Weight |
Approx 140g |
|
Certificate |
CE/ROHS |
|
Model |
M-3880M |
|
Sensor |
2/3 " CMOS (Mono) 8MP |
|
Resolution/Frame |
3968 × 2232 22FPS |
|
1980 × 1116（BIN2) 22FPS |
|
|
Any ROI |
|
|
Pixel Size |
2.5μm |
|
Scanning Tpye |
Progressive scan /Continuous Output |
|
Shutter |
Rolling Shutter |
|
Tigger |
Software Trigger/hardware Trigger |
|
Exposure Time |
0.038ms~1000ms |
|
Gain |
1x – 8x；Length：0.125 |
|
Image Data Format |
8Bit / 12Bit Optional |
|
Spectral Range |
380nm ～ 1100nm |
|
Image proceessing (ISP） |
platform integrated |
|
Exposure |
Manual/Auto/Area |
|
White Balance |
Auto/One-time/Area/ |
|
Firmware Update |
Support |
|
Product ID |
User-defined |
|
Image format |
RAW、BMP、JPG、PNG |
|
Programable control |
Speed,Image Size,Gain,Anti-flick,Gama,Contrast,RGB Gain,Saturation, Black level,Sharpness,2D noise reduction,3D noise reduction |
|
Systems |
Windows XP 32Bit；Windows 7/8/8.1/10 32/64Bit |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB3.0 5Gbps (B type) |
|
Rated Power (W) |
<2.0W |
|
Power supply |
USB 5V |
|
Working Environment |
Temperature: 0℃ ~ 50℃；Humidity:10% - 90%RH（No condensation） |
|
Storage Environment |
Temperature:-20℃ ~ 60℃；Humidity:10% - 60%RH |
|
Lens Mount |
C Mount |
|
Product Size |
44x44x39mm |
|
Weight |
150g |
|
Model |
M-3880 |
|
Sensor |
2/3 " CMOS (Color) 8MP |
|
Resolution/Frame |
3968 × 2232 22FPS |
|
1980 × 1116（BIN2) 22FPS |
|
|
Any ROI |
|
|
Pixel Size |
2.5μm |
|
Scanning Tpye |
Progressive scan /Continuous Output |
|
Shutter |
Rolling Shutter |
|
Tigger |
Software Trigger/hardware Trigger |
|
Exposure Time |
0.038ms~1000ms |
|
Gain |
1x – 32x；Length：0.125 |
|
Image Data Format |
8Bit / 12Bit Optional |
|
Spectral Range |
380nm ～ 650nm |
|
Image proceessing (ISP） |
platform integrated |
|
Exposure |
Manual/Auto/Area |
|
White Balance |
Auto/One-time/Area/ |
|
Firmware Update |
Support |
|
Product ID |
User-defined |
|
Image format |
RAW、BMP、JPG、PNG |
|
Programable control |
Speed,Image Size,Gain,Anti-flick,Gama,Contrast,RGB Gain,Saturation, Black level,Sharpness,2D noise reduction,3D noise reduction |
|
Systems |
Windows XP 32Bit；Windows 7/8/8.1/10 32/64Bit |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB3.0 5Gbps (B type) |
|
Rated Power (W) |
<2.0W |
|
Power supply |
USB 5V |
|
Working Environment |
Temperature: 0℃ ~ 50℃；Humidity:10% - 90%RH（No condensation） |
|
Storage Environment |
Temperature:-20℃ ~ 60℃；Humidity:10% - 60%RH |
|
Lens Mount |
C Mount |
|
Product Size |
44x44x39mm |
|
Weight |
150g |
|
Model |
M-31200M-H |
|
Pixels |
12MP(Mono) |
|
Sensor Size |
1" CMOS |
|
Pixel Size |
3.1μm x 3.1μm |
|
Max Resolution |
4096(H) x 3072(V) |
|
Frame rate |
15fps |
|
BIN |
2x2/3x3/4x4 |
|
ROI |
Any ROI |
|
Shutter |
Rolling shutter |
|
Exposure Time |
100μs ～ 10s |
|
Spectral Range (nm) |
380nm~1050nm |
|
Image data format |
8bit/10bit RAW |
|
Working Mode |
Continuous output/software trigger |
|
Software Interface |
DirectShow/Twain |
|
On-board buffer |
64MB |
|
Exposure |
Manual / Auto/ Area Exposure |
|
White Balance |
Manual/One-time/Automatic/Area (Only for color camera) |
|
Image processing |
Speed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/ 2D,3D Noise Reduction/（Saturation only for color camera） |
|
User Memory |
32K bit |
|
Product ID |
user-defined |
|
Systems |
Windows XP (32bit);Windows 7 (32bit/64bit);Windows 8 (32bit/64bit);Windows 8.1 (32bit/64bit)/Window 10(64bit) |
|
Data Interface |
USB3.0 Type-B |
|
Transmission Distance |
5 meters |
|
Trigger Port |
N/A |
|
Rated Power(W) |
<2.0W |
|
Working Temperature |
0~50℃ |
|
Working Humidity |
10~90%RH( No condensation) |
|
lens Mount |
C / CS Mount |
|
Product Size (mm) |
44mm * 44mm * 39mm（Exclude lens extension ring） |
|
Weight |
Approx 140g |
|
Certificate |
CE/ROHS |
|
Model |
M-31200-H |
|
Pixels |
12MP(color) |
|
Sensor Size |
1" CMOS |
|
Pixel Size |
3.1μm x 3.1μm |
|
Max Resolution |
4096(H) x 3072(V) |
|
Frame rate |
15fps |
|
BIN |
2x2/3x3/4x4 |
|
ROI |
Any ROI |
|
Shutter |
Rolling shutter |
|
Exposure Time |
100μs ～ 10s |
|
Spectral Range (nm) |
380nm~650nm |
|
Image data format |
8bit/10bit RAW |
|
Working Mode |
Continuous output/software trigger |
|
Software Interface |
DirectShow/Twain |
|
On-board buffer |
64MB |
|
Exposure |
Manual / Auto/ Area Exposure |
|
White Balance |
Manual/One-time/Automatic/Area (Only for color camera) |
|
Image processing |
Speed/Image size/ Exposure/ Gain/ GAMMA / Contrast/Black Level/ Sharpness/ 2D,3D Noise Reduction/（Saturation only for color camera） |
|
User Memory |
32K bit |
|
Product ID |
user-defined |
|
Systems |
Windows XP (32bit);Windows 7 (32bit/64bit);Windows 8 (32bit/64bit);Windows 8.1 (32bit/64bit)/Window 10(64bit) |
|
Data Interface |
USB3.0 Type-B |
|
Transmission Distance |
5 meters |
|
Trigger Port |
N/A |
|
Rated Power(W) |
<2.0W |
|
Working Temperature |
0~50℃ |
|
Working Humidity |
10~90%RH( No condensation) |
|
lens Mount |
C / CS Mount |
|
Product Size (mm) |
44mm * 44mm * 39mm（Exclude lens extension ring） |
|
Weight |
Approx 140g |
|
Certificate |
CE/ROHS |
|
Model |
M-32000 |
|
Sensor |
1" CMOS (Color) 20MP |
|
Resolution/Frame |
5472 × 3678 9.6FPS |
|
3840 × 2160 （ROI） 9.6FPS |
|
|
2736 × 1824（BIN2） 9.6FPS |
|
|
1920 × 1080（ROI + BIN2） 9.6FPS |
|
|
1824 × 1226 （BIN3） 9.6FPS |
|
|
Any ROI |
|
|
Pixel Size |
2.4μm |
|
Scanning Tpye |
Progressive scan /Continuous Output |
|
Shutter |
Rolling Shutter |
|
Tigger |
Software Trigger/hardware Trigger |
|
Exposure Time |
0.38ms ～ 60s |
|
Gain |
1x – 5x；Length：0.125 |
|
Image Data Format |
8Bit / 12Bit Optional |
|
Spectral Range |
380nm ～ 650nm |
|
Image proceessing (ISP） |
platform integrated |
|
Exposure |
Manual/Auto/Area |
|
White Balance |
Auto/One-time/Area/ |
|
Firmware Update |
Support |
|
Product ID |
User-defined |
|
Image format |
RAW、BMP、JPG、PNG |
|
Programable control |
Speed,Image Size,Gain,Anti-flick,Gama,Contrast,RGB Gain,Saturation, Black level,Sharpness,2D noise reduction,3D noise reduction |
|
Systems |
Windows XP 32Bit；Windows 7/8/8.1/10 32/64Bit |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB3.0 5Gbps (B type) |
|
Rated Power (W) |
<2.0W |
|
Power supply |
USB 5V |
|
Working Environment |
Temperature: 0℃ ~ 50℃；Humidity:10% - 90%RH（No condensation） |
|
Storage Environment |
Temperature:-20℃ ~ 60℃；Humidity:10% - 60%RH |
|
Lens Mount |
C Mount |
|
Product Size |
44x44x39mm |
|
Weight |
150g |
