XDS-3BYinverted five wave bands fluorescent microscope is composed of inverted microscope and Epi-fluorscent microscope.The inverted microscope has the feature to observe the specimen in Culture flask and Petri dish. Epi-fluorescent device applies to the fluorescent microscopy.It is equipped with infinite long working distance big numeral aperture Plan Apochromatic objective,phase contrast kit and phase contrast objectives.The transparent alive objects can be observed without dyeing.Epi-fluorescent microscope adopts LED excitation which controlled by touch screen to make fluorescent image clear.Long working distance condenser can contain higher culture dish and specimen.This equipment is specially suitable for micro research of living cells and organization,fluidity and sediment.It is an ideal equipment for researching treatment,epidemic prevention and farming,stock raising & forestry department,etc.
|
Specification |
|
|
Optical system |
infinite optical system |
|
viewing head |
Compensation Free Trinocular Head Inclined at 45° (50mm-75mm) |
|
Eyepiece |
PlanWF10×/22mm |
|
Objective |
infinite L.W.D.big numerical aperture plan appochromatic objective 4×/0.15（L.W.D.21.6mm) ,cover-glass thickness 1.5mm 10×/0.3（L.W.D.3mm）,cover-glass thickness 1.5mm 20×/0.5（L.W.D.4.27mm）,cover-glass thickness 1.5mm 40×(S) /0.6（L.W.D.2.23mm）,cover-glass thickness 1.5mm |
|
Nosepiece
|
Sextuple Nosepiece |
|
Stage |
Double layer mechanical stage |
|
Stage Size:242mm×172mm |
|
|
Moving Range :75mm×40mm |
|
|
Low located XY adjusting hand wheel |
|
|
Focusing |
Coaxial coarse & fine focusing adjustment, fine focusing scale value 0.001mm |
|
Light Source
|
Transmission illumination Halogen Bulb 12V/30W,AC85V-230V, brightness adjustable Epi-Fluorescent illumination Five wave bands LED source controlled by touch screen,LED 8W, AC85V-230V,brightness adjustable |
|
Fluorescence attachment |
G,B,BV,V,UV |
|
Condense |
Abbe condenser,working distance28mm |
|
Phase contrast device |
Contrast table（28mm）,Centering telescope |
|
Filter |
Blue,green,yellow,frosted glass |
|
Optional Accessory
|
Eyepiece:WF10×/20mm,cross hair with reticle 0.1mmWF15×/17mm,WF20×/12.5mm |
|
Abbe condenser,Working distance 70mm,Phase contrast turret（70mm） |
|
|
Photography attachment and CCD C-mount:0.5X,0.57X,0.75X |
|
|
Infinite L.W.D big numerical aperture plan:100×(dry)/N.A.0.9 |
|
|
4X/0.15（L.W.D.21.6mm,phase contrast）,cover glass thickness 1.5mm 40X/0.60（L.W.D.2.23mm,phase contrast）,cover glass thickness 1.5mm |
|
|
130Mega,200Mega,300Mega,500Mega,1000Mega pixels digital camera eyepiece |
|
|
Image analysis software |
|
