MIC-JY7 five wave bands LED fluorescent microscope is widely used in biology,medicine,immunology,oncology,genetics,materials science and other fields.It has five wave bands as G,B,BV,V,U,and meanwhile,the conventional transmission observation can be proceeded.High precision filters and LED revolver system makes the conversion of the different wave bands flexible,soft and accurate positioning.It also ensures that each wave band can be illuminated by excitation light fully and equably.High quality optical system and advanced stray light elimination system greatly increased the Signal-to-Noise of the fluorescent image.Large N.A fluorescent objectives greatly increased the fluorescent intensity. It can make you observe the satisfactory fluorescent effect.Humanized configuration design,convenient operation system and novel appearance would be your best choice
|
Specification |
|
|
Optical system |
infinite optical system |
|
viewing head |
Compensation Free Trinocular Head Inclined at 30° (50mm-75mm) |
|
Eyepiece |
PlanWF10×/22mm |
|
Objective |
infinite Plan large N.A fluorescent objectives 4×/0.15（W.D.=21.6mm) 10×/0.35（W.D.=2.9mm） 20×/0.60（W.D.=1.5mm） 40× /0.75（W.D.=0.6mm） |
|
Nosepiece |
Sextuple Nosepiece |
|
Stage |
Double layer mechanical stage |
|
Stage Size：180mm×160mm |
|
|
Moving Range ：80mm×50mm |
|
|
Focusing |
Coaxial coarse & fine focusing adjustment, fine focusing scale value 0.002mm |
|
Light Source
|
Epi-illumination: Kohler illumination with aperture iris diaphragm and field iris diaphragm LED bulb 3V/5W,AC 85V-230V,brightness adjustable |
|
Transmission illumination: Kohler illumination with aperture iris diaphragm and field iris diaphragm 3W LED bulb,AC 85V-230V, brightness adjustable |
|
|
Fluorescence attachment |
G、B、BV、V、UV |
|
Optional Accessory
|
Eyepiece：WF10×/20mm,WF20×/12.5mm |
|
Objective:infinite Plan large N.A fluorescent objective |
|
|
100x/0.90 (Dry) (W.D.=0.62mm) |
|
|
Photography attachment and CCD C-mount: 0.5X,0.57X,0.75X |
|
|
Image analysis software |
|
|
Fluorescent digital CCD |
|
