MIC-Intescope Item

PC

Order No

MIC-Intescope frame,One-piece construction from arm to base.

9.7 inch IPS retina touch screen display, resolution to 2048x1536

5 million/16 million mega pixel digital imaging, single pixel can reach 2.2UM/1.335um

Power full inner fixed software with ordinary measurement and test such as cell number counting

Provide HDMI interface and other interface to any other HD display or projector

●

MI1

UCIS Infinity Independent Achromatic Optical Design

●

110/220V，50/60Hz

●

Coaxial coarse and fine focusing knob, height adjustable.

●

Head

Binocular Tube, Interpupillary distance 48-75mm,30°inclined,360° rotate-able,diopter adjustable.

●

MSI2

Plan

Eyepiece

WF10X/20, High eye-point up to21mm.

●●

E1020PA

WF10X/22, High eye-point up to21mm.

○○

E1022PC

WF16X/14

○○

E1614WB

WF10X/20(Pointer), High eye-point up to21mm.

○

E1020GA

WF10X/22(Pointer), High eye-point up to21mm.

○

E1022GC

Reticule Eyepiece: CROSSWF10X/20

○

E1020RA

Reticule Eyepiece: CROSSWF10X/22

○

E1022RC

Centering Telescope

○

CTE

Infinity

Plan

Objectives

Plan 2X/0.06 ∞/-, WD3.55

○

WB-P4A

Plan 4X/0.10 ∞/-,WD12.31

●

WB-P4C

Plan 10X/0.25 ∞/0.17,WD5.03

●

WB-P10C

Plan 20X/0.40 ∞/0.17,WD2.71

○

WB-P20C

Plan 40X/0.65 ∞/0.17, WD0.72 (Spring)

●

WB-P40C

Plan 60X/0.80 ∞/0.17, WD0.69 (Spring)

○

WB-P60C

Plan 100X/1.25 ∞/0.17, WD0.17 (Spring,Oil)

●

WB-P100C

Condenser

Abbe condenser: NA 1.25, with iris diaphragm,with socket to accommodate PH-slide.Condenser center adjustable, color-coded diaphragm scale markings corespondent with the objectives of different powers.

●

JG3

Stage

Rackless Mechanical Stage: 190x150mmplatform, with X/Y travel of 78x54mmby low-positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide.

●

ZT4A

Revolving

Nosepiece

quadruple, inward facing.

●

ZQ480

quintuple, inward facing

○

ZQ580

Illumination Kohler, With field diaphragm

●

KL3A

Electrical

Parts

For 3W LED Bulb, super high brightness illumination

●

DQ3

Filter

Blue

●

LA2-0011

Green

○

LU2-0011

Yellow

○

LH2-0011

Grass Glass

○

LB2-0011

Filter

Holder

Filter Holder: (Attached to the Kholer)

for more than one filter.

●

LA1-0071

Immerse Oil

8ml

●

BZ-0027

Allen Screw Driver

φ2mm

●

BZ2-0018

Power Line

1.8m, CE certified

●

BZ-0021

Package

Inner package: foam, plastic bag;

Out Package: Carton

●

BZ3-0011A
