· WF10x plan eyepieces, 18mm field of view
· Seidentopf trinocular viewing head, inclined 30º, rotatable 360º
· 48-75mm interpupillary distance settings
· ±5 Diopter adjustment
· Quadruple nosepiece inward facing with positive click stops
· Infinity Achromatic 4x, 10x, 40x(S) and 100x (S/Oil) objectives
· Right hand controls, low position, mechanical stage, 140mm x 135mm, movement range 75mm x 45mm
· N.A. 1.25 Abbe condenser with iris diaphragm, with phase-contrast/dark-field socket
· Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity 0.001mm
· 1X C-Mount
· 6 volt 20 watt halogen illumination, 110-240V wide voltage
· Dust cover, clear blue filter, power cord, immersion oil
|
Order No. |
Specification |
MIC-AX22 |
MIC-AX23 |
|
MIC-AX2 |
Microscope Frame |
● |
● |
|
MS3A |
Binocular, Interpupillary distance 48-75mm, 30°inclined, 360° rotatable, diopter adjustable |
● |
|
|
MT3A |
Trinocular, Interpupillary distance 48-75mm, 30°inclined, 360° rotatable, diopter adjustable |
|
● |
|
E1018PB |
10X18mm Eyepieces |
●● |
●● |
|
E1020PB |
10X20mm Eyepieces |
○○ |
○○ |
|
E1613PA |
16X13mm Eyepieces |
○○ |
○○ |
|
E1018GB |
10X18mm Eyepiece (Point) |
○ |
○ |
|
E1020GB |
10X20mm Eyepiece (Point) |
○ |
○ |
|
E1020RB |
10X20mm Reticule Eyepiece |
○ |
○ |
|
E1018RA |
10X18mm Reticule Eyepiece |
○ |
○ |
|
WB-X4C |
Infinity Achromatic Objective 4X |
● |
● |
|
WB-X10C |
Infinity Achromatic Objective10X |
● |
● |
|
WB-X40C |
Infinity Achromatic Objective40X(S) |
● |
● |
|
WB-X100C |
Infinity Achromatic Objective100X(S)/(Oil) |
● |
● |
|
WB-P4C |
Infinity Plan Achromatic Objective 4X |
○ |
○ |
|
WB-P10C |
Infinity Plan Achromatic Objective 10X |
○ |
○ |
|
WB-P20C |
Infinity Plan Achromatic Objective 20X(S) |
○ |
○ |
|
WB-P40C |
Infinity Plan Achromatic Objective 40X(S) |
○ |
○ |
|
WB-P60C |
Infinity Plan Achromatic Objective 60X(S) |
○ |
○ |
|
WB-P100C |
Infinity Plan Achromatic Objective 100X(S)/(Oil) |
○ |
○ |
|
JG2C |
Abbe Condenser |
● |
● |
|
ZT3 |
Mechanical Stage, Size: 140mmX135mm, Range: 75x45mm |
● |
● |
|
ZT2 |
Mechanical Stage, Size: 156mmX138mm, Range: 76x54mm |
○ |
○ |
|
ZQ470 |
Quadruple, Revolving Nosepiece |
● |
● |
|
ZQ570 |
Quintuple, Revolving Nosepiece |
○ |
○ |
|
JZ3-1000 |
Kohler Illuminator(No Field Diaphragm) |
● |
● |
|
DQ3 |
Electrics for 6V20W Halogen |
● |
● |
|
DQLC1 |
Electrics for 3W LED(with Rechargeable Battery) |
○ |
○ |
|
DQL1 |
Electrics for 3W LED |
○ |
○ |
|
SX2 |
0.5X C-Mount |
○ |
○ |
|
SX3 |
1X C-Mount |
|
● |
|
SX4 |
0.25X C-Mount |
○ |
○ |
|
LA2-0011 |
Blue Filter (φ32, No Blue Filter for LED) |
● |
● |
|
LU2-0011 |
Green Filter (φ32) |
○ |
○ |
|
LH2-0011 |
Yellow Filter (φ32) |
○ |
○ |
|
LB2-0011 |
Ground Grass (φ32) |
● |
● |
|
PQ1A |
Polarizer |
○ |
○ |
|
PY1 |
Analyzer |
○ |
○ |
|
FG1 |
Reflected Mirror |
○ |
○ |
|
BZ-0022A |
6V20W Osram Halogen Bulb |
● |
● |
|
BZ-0023 |
250V/3.15A Φ5X20 Fuse |
●●● |
●●● |
|
DQL1A-1000 |
3W LED Bulb |
○ |
○ |
|
UDCH-5300 |
LED Rechargeable Battery |
○ |
○ |
|
BZ-0027 |
Immersion Oil |
● |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
