Digital Ultrasonic Detector MIC-L552C |
|
||
|
Display |
Multi-color |
||
|
Scanning |
2.5-10000mm |
||
|
Range(mm) Velocity Range |
100～20000（m/s） |
||
|
Vertical linearity |
≤4% |
||
|
error Dynamic Range |
≥34dB |
||
|
Horizontal linearity |
≤0.2% |
||
|
error Testing sensitivity |
≥65dB |
||
|
Storage channel |
100 |
||
|
Storage |
300 |
||
|
Gain Range(dB) |
0~110 |
||
|
Weight |
1.2kg |
||
|
Overall dimension |
240×160×40mm |
||
|
TCG curve |
√ |
||
|
B Scan |
√ |
||
|
PC |
√ |
||
|
Video |
√ |
||
|
Optional Accessories |
BNC cables 、PC software |
||
|
Standard Delivery |
Main Unit 、Straight probe 、Angle probe 、Power adapter 、BNC cables 、 PC software |
|
|
|
Function & Feature: |
|
||
|
●With the durable shell,oil-proof, water-proof and dust-proof; ●26 million colors ultra-bright display, adjustable brightness, suitable for both intense and low light working environment; ● Battery with a good performance of safety and environment-friendly, can work for 10 hours. ● Time records: track and store records of testing date, time; ● With power outage protection, stored data will not be lost; ● Testing parameters can be automatically tested or preset; ● With digital suppression, no effects for the gain and linearity; ● Gain Compensation: Correcting dB attenuation caused by surface roughness, surface curvature, distant-testing of thick piece and other factors; ● Two input methods: Angle and K values ● Echo frequency analysis ● Power indicator ● Strobe Audible and visual alarm ● DAC Audible and visual alarm ● Screen lock and unlock ● Clock display |
|
||
|
Application Fields: |
|
||
|
Widely used in steel,boilers, pressure vessels, aerospace, power, petroleum, chemical, marine, military, petroleum pipeline, ship-manufacturing, automobile, machinery manufacturing, metallurgy, metal processing, steel structure, railway transportation, nuclear power, and relevant departments in colleges and universities. |
|
||
|
|
|||
